Description

It includes both with and without graphite. The particle sizes range from 1.0 to 1.5mm, 1.5 to 2.0mm, and 2.0 to 3.0mm. It melts and rapidly expands within the injection sleeve and at the tip, forming an excellent lubricating film inside the sleeve due to its capillary effect. It's easy to use, eliminating the need for traditional drop-coating spray systems used with oil-based or water-based products.

Appearance: White, yellow, clear (excluding graphite), granular.

Application Range: Molding bushes with diameter ranging from 50-120mm; Black Granules: Contain graphite, spherical in shape.
Density at 20℃: 0.5-0.7 cm³.
Application Range: Shot sleeve with diameter ranging from 50-160mm.

[Usage Instructions]

Add granules using a particle emitter into the casting chamber
Usage based on different punch diameters
60mm 0.4-0.5g
80mm 0.6-0.8g
100mm 1.0-1.3g
140mm 1.7-2.5g
150mm 2.2-4.0g
The determination of usage depends on the casting weight and requires empirical testing.

【Advantages】

No contamination from general oil-based lubricants.
2. Reduce the occurrence rate of casting pores.
3. Extends the service life of the plunger tube and reduces the negative effects caused by friction.
4. The lifespan of the punch used in die casting is generally doubled compared to using pure oil lubrication.
Increase jet speed.
6. Complete consumption of particles during casting, with no lubricant contamination.
7. The die-casting parts have no oil stains on the surface, presenting a clean and glossy finish.
8. When the gating, runners, and sprue are recycled for use, they are free of oil stains, smoke, and air pollution.
9. No wastewater treatment required, no water cooling system or cleaning injection nozzle needed.
10. Highly economical, saving on expenses.
11. Enhance safety during the process.
