Product Description

Cummins On-Highway diesel generator sets are designed, manufactured, and tested to Cummins' global standards, providing customers with a reliable, integrated all-in-one power generation system that excels in continuous, standby, and peak load operations.

➊ Meets the ISO 8528-2005 and GB/T 2820-2009 standards for "AC Generating Sets Driven by Reciprocating Internal Combustion Engines."

➋ The design and manufacturing units of the generator sets have both passed ISO9001 or ISO9002 certification.

➌ Cummins offers a 1-year or 1000-hour runtime warranty, covering the entire genset for engine, generator, and control system warranty.

➍ A nationwide professional service network provides 24/7 after-sales service and technical support to customers.

Performance Features

■ Advanced design and exquisite craftsmanship Adaptable to stringent operating conditions, with high strength and robust load-bearing capacity.

■ Holset Exhaust Bypass Valve Enhanced dynamics.

■ Integrated design Cylinder block, cylinder head, and other parts are "one for many," reducing connecting components. These parts are 40% fewer than those of similar engines, significantly lowering the failure rate.

■ Excellent reliability Forged steel camshaft and crankshaft, high-strength cylinder block design, high rigidity, excellent high-pressure resistance, and longer service life.

■ Platform pattern honing designed cylinder sleeve Effectively prevents oil leakage with perfect geometric construction.

■ Rotor High-Pressure Fuel Pump Lower fuel consumption and effectively reduce noise.

Environmental Requirements

Altitude (m): ≤1000

Fuel Standard: 0# Light Diesel Fuel

Atmospheric Pressure (kPa): ≥ 89.9

Engine Oil Standard: CF / 15W-40

Inlet Temperature (℃): ≤40

Water pH Range: 6.5-8

Relative Humidity: ≤60%

Mold Growth Level on Surface: ≤GB/T2423.16/Grade 2

Earthquake Resistance: Horizontal acceleration 0.2g, vertical acceleration 0.1g

Generator set specifications

Model Type: Open Shelves

Engine Model: DC30GF

Standby Power (kW): 30

Typical Power (KW): 28

Unit Size (mm): 1650×800×1260

Engineered Weight (kg): 697

RPM: 1500

Fuel Consumption (g/kw.h): 214

Frequency (Hz): 50

Transient Voltage Regulation: ≤-15%/+20%

Steady-state voltage regulation: ≤±1%

Voltage Stabilization Time: ≤3 sec

Voltage fluctuation rate: ≤0.5%

Voltage waveform distortion: ≤8%

Steady-state frequency adjustment rate: ≤5%

Transient Frequency Adjustment Rate: ≤-10%/+12%

Stable Frequency Time: 3 sec

Frequency fluctuation rate: ≤1.5%

Engine specifications

Diesel Engine Brands: Cummins / Cummins

Manufacturer: (DCEC) Dongfeng Cummins Engine Co., Ltd.

Diesel Engine Model: 4BT3.9-G2

Backup Power (KW): 40 KW

Number of Cylinders/Arrangement: 4-Cylinder/Inline

Compression Ratio: 16.5:1

Bore*Stroke (mm): 102×120

Displacement (L): 3.9

Oil Pressure (kPa): 345

Engine Oil Temperature (℃): ≤121

Oil Capacity (L): 9

Coolant Capacity (L): 7.9 (Engine Only)

Fuel System: NYC Type A Inline Pump

Cooling Method: Closed-loop Water Cooling

Speed Control: Electronic Speed Regulation

Startup Method: DC24V Electric Start

Inlet Method: Turbocharged

Type: Four-stroke

Constant Load Steady-State Variability: ±0.25%

Power Deviation: ≤±5%

Generator specifications

Generator Brand: Stamford/Stanford

Manufacturer: Cummins Generator Technologies (China) Co., Ltd.

Generator Model: PI144H S1L2-J1

Capacity: 30KW

Voltage: 400V/230V

Form: Brushless, Single-Bearing, Rotating Magnetic Field

Excitation System: Self-excitation, Automatic Voltage Regulation

Winding Structure: 2/3 Pitch

Number of phases: 3-phase 4-wire

Insulation Grade: H-class

Power Factor: COSΦ = 0.8 lagging

Phone Interference Factor: TIF: <50

Wiring: Y-type connection

Phone Harmonic Factor: THF < 2%

Protection Class: IP23

Radio Frequency Interference: Meets BS800 and VDE G, N levels

Meets Standards: GB755, BS5000 Part 3, VDE0530, NEMA MG1-22, IEC-34, GSA C22-100, AS1359

Standard Configuration

Engine Components: Engine, Diesel Filter, Air Filter, Oil Filter, Charger, Starter Motor.

Generator Parts: Generators, Air Circuit Breakers.

Control Systems: LCD digital display controller, electronic speed controller.

Other Parts: Water Tank Radiator, Steel Base, Vibration Dampers.

Attachment Part: Muffler, Battery, Battery Cables, Engine Oil, Shock Absorbers.

Standard Implementation

Military Standard  GJB 5785-2006

National Standard GB/T 2820-2002

Communication Standard YD/T 502-2007

Industry Standard      JB/T 10303－2001

Environmental Certification - Noise & Vibration Class A/Exhaust Class A

Taier Quality Certification YD/T502-2007*
