Product Description

Cummins on-highway diesel generator sets are designed, manufactured, and tested to Cummins' global standards, providing customers with a reliable, integrated one-stop power generation system with exceptional performance in continuous, standby, and peak load operations.

➊ MeetsISO 8528-2005 and GB/T 2820-2009 Standards for "AC Generating Sets Driven by Reciprocating Internal Combustion Engines"

➋ Design and manufacturing of the generator sets have both passedISO9001 or ISO9002 Certification.

➌ Cummins offers1-year or 1,000 operating hours warranty, covering the entire genset unit, including the engine, generator, and control system.

➍ A nationwide professional service network serving customers24/7 after-sales service and technical support.

Performance Features

■ Design and Manufacturing:Advanced design, exquisite manufacturing, reliable and durable.

■ Bosch Inline Fuel Pump:Higher oil pressure ensures more complete combustion, resulting in less energy loss, stronger power, and greater fuel adaptability.

■ HorssettHolset Turbocharger:Equipped with an integrated exhaust bypass valve, featuring low-speed responsiveness and strong power.

■ Integrated design:Part quantity is nearly less than that of similar products.25%, lower failure rate, easier maintenance.

■ Excellent reliability:The cylinder sleeve features a platform pattern honing design and a corrosion-resistant high-nickel cast iron piston, significantly reducing oil consumption and enhancing durability for a longer service life.

Environmental Requirements

Altitude(m)：≤1000

Fuel Standard:0# Diesel Fuel

Atmospheric Pressure(kPa)：≥89.9

Oil Standard:CF/15W-40

Intake Temperature(℃)：≤40

Water QualitypH Level: 6.5～8

Relative Humidity:≤60%

Mold Growth Level on Surface: ≤GB/T2423.16/Grade 2

Seismic Resistance: Horizontal Acceleration0.2g vertical acceleration, 0.1g

Generator set specifications

Model: Open Shelves

Engine Model:DC150GF

Standby Power(KW)：150

Common Power(KW)：130

Engineered dimensions(mm)：2400×840×1345

Engineered Weight(kg)：1700

RPM(r/min)：1500

Fuel Consumptiong/kw.h)：210

Frequency(HZ)：50

Transient Voltage Regulation Ratio:≤-15%/+20%

Steady-state voltage regulation ratio:≤±1%

Voltage Stabilization Time:≤3sec

Voltage fluctuation rate:≤0.5%

Voltage waveform distortion:≤8%

Steady-state frequency adjustment rate:≤5%

Transient Frequency Adjustment Rate≤-10%/+12%

Stable Frequency Time:3sec

Frequency Volatility:≤1.5%

Engine specifications

Diesel Engine Brand:Cummins/Cummins

Manufacturer:Dongfeng Cummins Engine Co., Ltd.

Diesel Engine Model:6CTA8.3-G2

Standby PowerKW）：163

Number of cylinders/Arrangement: 6 cylinders/inline

Compression Ratio:17.0:1

Bore diameter* Travel (mm): 114×135m

DisplacementL)：8.3

Oil PressurekPa)：276～414

Oil Temperature℃)：≤121

Oil capacity(L):23.8

Coolant Capacity12.3 (Engine only)

Fuel System:PB Inline Pump

Cooling Method: Closed-loop Water Cooling

Speed Control Method: Electronic Speed Control

Start-up Method:DC24V Electric Start

Air Intake Method: TurbochargedWater-air air-cooling

Type: Four-stroke

Constant Load Steady-State Variability±0.25%

Power Deviation:≦±5%

Generator specifications

Generator Brand:Stamford/Stanford

Manufacturer: Cummins Generator Technologies (China) Co., Ltd.

Generator Model:UCI274F

Capacity:150KW

Voltage:400V/230V

Form: Brushless, Single-Bearing, Rotating Magnetic Field

Excitation System: Self-excitation, Automatic Voltage Regulation

Winding structure:2/3 Pitch

Phase Number: Three-phase Four-wire

Insulation Grade:Grade H

Power Factor:COSΦ = 0.8 lag

Phone Interference Coefficient:TIF：<50

Wiring:Y-connection

Phone Harmonic Coefficient:THF：<2%

Ingress Protection Rating:IP23

Radio Interference: CompliantBS800 and VDE Class G, N

Meets Standards:GB 755, BS 5000 Part 3, VDE 0530, NEMA MG1-22, IEC 34, GSA C22-100, AS 1359

Standard Configuration

Engine Parts: Engine, Diesel Filter, Air Filter, Oil Filter, Charger, Starter Motor.

Generator parts: Generator, Air Circuit Breaker.

Control System:LCD liquid crystal display controller, electronic speed controller.

Other Components: Water Tank Radiator, Steel Base, Vibration Dampers.

Attachment: Muffler, Battery, Battery Wire, Engine Oil, Shock Absorber Pads.

Standard of Execution

Military Standard  GJB 5785-2006

National Standards  GB/T 2820-2002

Communication Standards  YD/T 502-2007

Industry Standards      JB/T 10303－2001

Environmental CertificationNoise and Vibration Class A / Exhaust Class A

Talyr Quality Certification  YD/T502-2007*
