280KW Cummins Generator Set Technical Specifications | |
Product Description | |
Cummins on-highway diesel generator sets are designed, manufactured, and tested to Cummins' global standards, offering customers a reliable and integrated power generation system with exceptional performance under constant load, standby, and continuous operation conditions. ➊ CompliantISO 8528-2005 and GB/T 2820-2009 standards for "AC Generator Sets Driven by Reciprocating Internal Combustion Engines" ➋ The design and manufacturing units of the generator sets have all passedISO 9001 or ISO 9002 Certification. ➌ Cummins offers1-year or 1000 operating hours warranty, covering the entire genset unit, including the engine, generator, and control system. ➍ A nationwide professional service network serving clients24/7 after-sales service and technical support. | |
Performance Features | |
■ Cummins patented technologyPT Fuel System, ultra-high injection pressure, ensures optimal engine atomization and complete combustion. ■ Holset exhaust gas turbochargers offer more complete intake, enhancing efficiency and further improving combustion. Reduce engine fuel consumption. ■ Air-to-air cooling technology ensures more complete intake and better fuel economy. ■ Replaceable wet cylinder liners, excellent heat dissipation, easy to replace. ■ The cylinder block and cylinder head both feature built-in pressure lubrication channels, offering a compact structure and low failure rate. ■ Composite oil filter, easy maintenance, reduces daily maintenance costs. | |
Environmental Requirements | |
Altitude(m)：≤1000 Fuel Standards:No. 0 Light Diesel Oil Atmospheric Pressure(kPa)：≥89.9 Oil Standard:CF/15W-40 Inlet Temperature(℃)：≤40 | Water QualitypH: 6.5-8 Relative Humidity:≤60% Mold Growth Level on Surface≤ GB/T2423.16/2 grade Seismic Resistance: Horizontal Acceleration0.2g vertical acceleration, 0.1g |
Generator Set Specifications | |
Model: Open Shelving Engine Model:C280GF Standby Power(KW)：300 Common Power(KW)：280 Engine size(mm)：3000×1060×1800 Engineered Weight(kg)：3450 RPM(r/min)：1500 Fuel Consumptiong/kw.h)：205 Frequency(HZ)：50 | Transient Voltage Regulation Ratio:≤-15%/+20% Steady-state voltage regulation:≤±1% Voltage stabilization time:≤3sec Voltage Fluctuation Rate:≤0.5% Voltage waveform distortion:≤8% Steady-state frequency adjustment rate:≤5% Transient Frequency Adjustment Rate≤-10%/+12% Frequency Stability Time:3sec Frequency Volatility:≤1.5% |
Engine specifications | |
Diesel Engine Brand:Cummins/Cummins Manufacturer:CCEC) Chongqing Cummins Engine Co., Ltd. Diesel Engine Model:NTA855-G1B Standby PowerKW）：321 Number of cylinders/Arrangement: 6-cylinder/Inline Compression Ratio:14.5:1 Bore diameter*行程 (mm): 140 x 152 DisplacementL)：14 Oil PressurePSI)：35～50 Oil Temperature℃)：≤121 | Oil capacity(L):38.6 Cooling Water Capacity(L)：60.6 Fuel SystemPT pump direct injection Cooling Method: Closed-loop Water Cooling Speed Control: Electronic Speed Control Startup Method:DC24V Electric Start Air Intake Method: TurbochargedChina Cold Type: Four-stroke60° Constant Load Steady-State Fluctuation Rate±0.25% Power Deviation:≦±5% |
Generator specifications | |
Generator Brand:Stamford/Stanford Manufacturer: Cummins Generator Technologies (China) Co., Ltd. Generator Model: HCI444D Capacity:280KW Voltage:400V/230V Form: Brushless, Single-Bearing, Rotating Magnetic Field Excitation System: Self-excitation, Automatic Voltage Regulation Winding structure:2/3 pitch Phase Configuration: Three-phase, four-wire | Insulation Grade:H Grade Power Factor:COSΦ = 0.8 lag Phone Interference Coefficient:TIF：<50 Wiring:Y connection Phone Harmonic Coefficient:THF：<2% Protection Level:IP23 Radio Frequency Interference (RFI): CompliantBS800 and VDE Class G, N Meets Standards:GB755, BS5000 Part 3, VDE0530, NEMA MG1-22, IEC-34, GSA C22-100, AS1359 |
Standard Configuration | |
Engine Components: Engine, Diesel Filter, Air Filter, Oil Filter, Charger, Starter Motor. Generator section: Generators, circuit breakers. Control System:LCD Liquid Crystal Display Controller, Electronic Speed Controller. Other Components: Water Tank Radiator, Steel Base, Vibration Dampers. Appendix: Muffler, Battery, Battery Cable, Engine Oil, Shock Absorber Pad. | |
Standard Compliance | |
Military Standard GJB 5785-2006 National Standards GB/T 2820-2002 Communication Standards YD/T 502-2007 | Industry Standards JB/T 10303－2001 Environmental CertificationNoise and Vibration Class A / Exhaust Class A Taylors Quality Certification YD/T502-2007* |
