Motor lead wires, lead wire prices, high-voltage motor lead wires, [10KV motor lead wires], 25 square motor lead wires, motor lead wire standards, motor lead wire manufacturers, lead wires
JFEYH-10KV, copper-core, ethylene propylene insulated, chlorosulfonated polyethylene sheathed high-voltage motor winding lead cables. Suitable for direct and permanent connection with motor windings and for connecting to the motor housing or to the connection posts on the motor housing. Our motor lead wires are compatible with major motor manufacturers and are also used for high-voltage switchgear connection wires.




JFEYH-10KV Motor Lead Wire Technical Requirements
1. Operating temperature +90℃
2. Rated voltage: 10,000V
3. Conductors are made of 196/0.40 tin-plated copper wire, with the finished product having a reference outer diameter of 22mm.
4. The allowable bending radius during cable laying should not be less than four times the diameter of the cable.
