MT-BS Long Axis Bright Field Metallographic Microscope System

MT-BSLong-axis bright-field metallographic system microscope

High-quality component design, simple and flexible configuration combinations, powerful metallographic testing functions——MT-BS is the recommended choice for observing large or thick samples.

Performance Features

All optical components are specially treated and coated with special layers.

Flexible and compact structure, adaptable for microscopic observations in various environments

Long working distance professional metallurgical objective lens, high magnification objectives utilize semi-apochromatic technology

Microscopic images with clear sharpness and high contrast can be obtained under various observation methods.

MT-BS--Independent metallographic testing system

Unlike traditional metallographic microscopes,OmitMT-BSCompact structure design chosen, featuring a small and lightweight appearance, and enhanced flexibility in operation.B3Large flat base and coarse-fine adjustment coaxial mount, overcoming the limitation of conventional metallographic microscopes that cannot observe thicker samples. Integrated with bright field, oblique illumination, polarized light,DICMultiple observation functions such as differential interference, selectable according to actual application.

MT-BS--Large-scale equipment's vision system

Integrating various observation methods with professional metallographic microscopy, the flexible and ingenious design makesMT-BSProfessional metallographic microscope that can be installed in large machinery equipment. Suitable for large sizesLCDPanels orPCDVisual systems for PCB manufacturing or inspection equipment. Images can be output to monitors or computers via camera interfaces for convenient and quick detection.

CompactLighting fixture

Single High-Power Unit5WWhiteLEDLightingWarm white light can effectively reduce the observer's visual fatigue.

Compact optical path design, lightweight structure for easy installation and weight reduction.

The converter features a precision bearing design, offering a smooth and comfortable hand feel during operation. It boasts high repeatability accuracy and good concentricity control after objective lens conversion. Converters with different hole positions can be configured according to requirements.

Wide ViewField hinge three-eye observation tube

30DegreeThree-way hinge observation tubeRelieves tension and fatigue during prolonged work, ensuring a comfortable observation state. The graduations on the observation tube facilitate the user's self-adjustment to a comfortable interpupillary distance range.Quick-release three-eye observation tube, featuring a compact inverted optical path design, with a lightweight structure for easy installation and weight reduction.

Extra-long working distance metallurgical objective

Brand-new, ultra-long working distance objective lens, featuring semi-apochromatic technology and multi-layer broadband coating, ensuring sharp and clear imaging throughout the field of view, with natural colors and bright, comfortable brightness.

Extra-long working distance design50XEffective working distance reaches8.0mm，100XThe objective lens also meets3.0mm,Significantly expanded the application fields.5X、 10X、 20X Objective lens design, through the selection of high-quality materials and optimized design, ensuresDICThe performance of the differential interference observation is exceptional.

We have designed a complete set of objective lenses that are suitable for both bright-field and dark-field illumination, with the dark-field illumination brightness being higher than that of traditional dark-field objectives.2Several times over.

Photography & Video Accessories

On the trinocular viewing tube, photographic and video devices can be attached to output the images observed by both eyes to a monitor or computer for image analysis, processing, storage, or transmission.

Utilize professionalCInterface and relay mirrors, compatible with digital cameras for quick photo-taking and image retrieval.

PolarizedDICAttachment

Insert the polarizer and analyzer into the slots of the illuminator. Simple polarized observation is possible.

Based on orthogonal polarized light, insertDlCPrisms, capable ofDICMicrointerference phase-contrast observation.DICTechnology can create a striking bas-relief effect from minute differences in the surface height of objects, significantly enhancing image contrast.
