Product Details
Primarily engaged in the sales and service of gas power generator sets, gasoline generators, diesel generator sets, variable frequency gasoline generators, portable generators, home generators, welding generators, diesel pumps, gasoline pumps, a variety of welding machines, and general mechanical products powered by these machines.
价 格Negotiable
最小起订0 piece库存0 piece
Business Card
Negotiable
Negotiable
Negotiable
Negotiable
10KW Gasoline Generator
Negotiable
400kw Silent Diesel Generator Oil
Negotiable
350 Dual-Use Welding Generator
Negotiable
500kw Silent Diesel Generator Dim
Negotiable
Water-cooled 15KW diesel generato
Negotiable
250KW Quiet Diesel Generator Daze
Negotiable
Fully Automatic 150KW Low Noise D
Negotiable
30kw Diesel Generator 3-Phase 4-W
Negotiable
Power Utility 100KW Small Diesel
Negotiable
50KW diesel generator for desert
Negotiable
250KW Diesel Generator, Dazee PowerFull copper brushless AC generators, brushless three-phase synchronous generators, represent a perfect blend of technology and craftsmanship. The stator winding ends feature a special layer winding technique and end箍 reinforcement structure, enhancing the winding's dust resistance and corrosion resistance. The rotor winding utilizes a special double-layer insulation technique with flat copper wire, providing the rotor with excellent inter-turn and inter-layer insulation, as well as superior mechanical and voltage resistance properties, effectively improving the generator's performance and service life. The vertical baking varnish drying process, along with overall high-speed dynamic balance testing, ensures the generator's insulation performance and smooth operation, with minimal vibration and low noise.
TO280000ETDetailed specifications
I. Technical Specifications
Rated Output： 250KVA
BackupPower： 260KVA
Rated Frequency： 50Hz
Rated Voltage： 400V
Rated Speed： 1500
Generator Type: Style
Startup Method: Electric start
Please provide the Chinese content you would like translated into American English. Number: Three-phase
Power Factor： COSΦ = 0.8 (lagging)
Adjustment Method:AVR (Automatic Voltage Regulator)
Steady-state voltage regulation:(%):≤±0.5
Voltage Fluctuations： (%):≤±0.5
Load Surge Voltage%： ≤±3
Steady-state Frequency Adjustment%： ≤±2
Engine Technical Specifications:
Power Model: TO28000ET
Cylinder arrangement: Inline
Cylinder Quantity:6-cylinder
Cooling Method: Forced closed-loop water cooling system
Supply Method: Direct喷射燃烧式
Speed control method: Mechanical Speed Control
Silencer: Industrial **Equipment**
Inlet Method: Turbocharger
Engine Oil Type: SAE 10W-30 (or CD)
Fuel Model: 0# -10#Diesel
Diesel Fuel Tank: 300L
Engine fuel consumption:224g/kw•h
Motor Technical Specifications:
Rated Power: 250KW
Wiring method: Three-phase four-wireY-type connection
Protection Grade: IP22
Insulation Grade:H Level
Motor Type: Brushless Motor
Other Configurations:
Dimensions of the Engine AssemblyL×B×H）：3980*1300*1950mm
Office Hours:8-10H
Engineered Weightkg）：2500/2700
250KW Diesel Generator - Dazao PowerThe engine is lighter and more compact, with lower sales costs and less noise, and better cold-starting performance, but it has lower thermal efficiency and higher fuel consumption rates. For motorcycles, chainsaws, and other small-power industrial machinery, two-stroke air-cooled engines are commonly used for their lightness and simplicity. Fixed small-power engines, which aim for a simple structure and lower cost, are mostly four-stroke water-cooled. Cars and light commercial vehicles generally use overhead valve water-cooled engines, but as fuel efficiency issues gain greater attention, these engines are increasingly used in such vehicles. For small aircraft, engines with hemispherical combustion chambers and air cooling are commonly used for their lightness and high power-to-weight ratio.
