Introduction to Steel Grating

Steel grating, also known as steel grate or grating plate, is made by welding flat steel and twisted steel. Durable and cost-effective compared to other products, steel grating is primarily used in power plant platforms, parking lot platforms, maintenance platforms, manhole covers, and tread plates. It is also employed in environmental protection equipment and wastewater treatment. Steel grating is widely used in various fields such as petrochemicals, electricity, water supply, wastewater treatment, port terminals, architectural decoration, shipbuilding, self-propelled parking lots, municipal engineering, and environmental protection engineering, for platforms, walkways, gangways, covers, manhole covers, ladders, fences, and more.

Steel Grating Plates

Also known as steel grating or grid plate, it is a type of steel product made by crossing flat steel bars at specific intervals with crossbars, then welded together to form a square grid pattern in the middle. It is primarily used for drain covers, steel structure platform panels, and step plates for steel ladders. The crossbars are typically made of twisted square steel.

Manufacturing Method of Steel Grating Plates: Steel grating plates are made by welding load-bearing flat bars and cross bars at specific intervals using a 200-ton hydraulic resistance welding automation machine to form the original plate. The plates are then processed through cutting, drilling, and edging, among other operations, to meet customer requirements. Spacing of Load-bearing Flat Bars: The spacing between adjacent load-bearing flat bars is commonly 30, 40, 50, and other sizes. Spacing of Cross Bars: The distance between adjacent cross bars is typically 50, 76, 80, 100, and other sizes, which can be produced according to customer specifications and customized in various steel grating plate models to meet customer needs.

Product Features of Steel Grating Plates:

1: High strength, lightweight structure.

2: Excellent corrosion resistance and durability.

3: Aesthetically pleasing with a glossy surface.

4: No dirt accumulation, no snow or rain buildup, no water pooling, self-cleaning, easy to maintain.

5: Good ventilation, lighting, heat dissipation, anti-slip, and explosion-proof properties.

Easy to install and dismantle.

Product Applications: Widely used in the petrochemical industry, tobacco sector, electricity, water supply, wastewater treatment, ports, wharfs, architectural decoration, shipbuilding, self-propelled parking lots, municipal engineering, environmental protection engineering, and other platforms. Also used for walkways, gangways, manholes, covers, ladders, fences, and ceilings in industrial and civil buildings such as large sports venues, exhibitions, large-scale commercial buildings, train stations, docks, and airports.

Hot-Dipped Galvanized Steel Grating

The product is a finished item made through deep processing, including cutting, notching, punching, and edging, from a base plate that is焊接 on a high-pressure resistance welding machine by arranging load flat steel and crossbars at certain intervals in a warp and weft pattern.

Hot-dip galvanized steel grating is categorized into the following types:

1. Hot-dip galvanized steel grating, categorized by manufacturing process, includes press-welded hot-dip galvanized steel grating and press-locked hot-dip galvanized steel grating.

2. Hot-dip galvanized steel grating is categorized by surface shape into toothed hot-dip galvanized steel grating and flat type hot-dip galvanized steel grating.

3. Type I hot-dip galvanized steel grating and composite hot-dip galvanized steel grating.

Marking Method:

(1) Hot-dip galvanized steel grating flat steel spacing: differentiated by series: Series 1 is 30mm; Series 2 is 40mm; Series 3 is 60mm.

(2) Hot-dip galvanized steel grating cross-bar spacing: Series 1 is 100mm, Series 2 is 50mm. Other specifications available upon request.

(3) Hot-Dip Galvanized Steel Grating: Made of Q23 steel or stainless steel, available in flat, anti-slip toothed, and I-section designs. Common sizes include 20*5, 25*5, 25*3, 32*5, 32*5, 40*5, 40*3, 50*5, 65*5, 75*6, 100*8, and 100*10.

(4) Hot-Dip Galvanized Steel Grating Crossbars: Made of round steel, twisted square steel, square steel, or hexagonal steel in material grade Q23 or 304 stainless steel. Twisted square steel is produced by drawing through square dies from round wire and twisting it, with common sizes including 5*5, 6*6, 8*8mm, etc.

Features include: High strength, lightweight structure: The sturdy grid pressure-welded structure offers high load-bearing capacity, light structure, and ease of hoisting; aesthetically pleasing and durable.

Hot-Dip Galvanized Steel Grating Applications: Widely used in platforms, walkways, gangways, manhole covers, ladder covers, fences, guardrails, etc., for fields such as petrochemicals, power plants, waterworks, sewage treatment plants, municipal engineering, and environmental protection engineering.

Hot-Dipped Galvanized Steel Grating

Hot-dip galvanized steel grating panels are one of the most commonly used products in steel grating applications, with wide-spread usage. After welding and forming, these panels undergo hot-dip galvanizing, offering not only an aesthetically pleasing appearance but also excellent corrosion and rust resistance, thereby extending their service life. They are highly favored by a large number of customers.

Hot-dip galvanized steel grating panels feature high strength and lightweight structure; their sturdy grid pressure-welded construction offers high load-bearing capacity, lightweight, and ease of hoisting; they also possess an aesthetically pleasing appearance and are durable.

Corrosion Resistance: A stable protective film forms on the zinc coating surface within the pH range of 6 to 12.5, offering good corrosion resistance.

Hot-dip galvanized steel grating applications: Widely used in platforms, walkways, bridges, manhole covers, ladder covers, fences, guardrails, etc., in fields such as petrochemicals, power plants, waterworks, sewage treatment plants, municipal engineering, and environmental protection engineering.

Heavy-duty steel grating

1. Heavy-duty steel grating introduction:

Heavy-duty steel grating refers to grating with bearing flat steel width over 65mm and thickness over 6mm, with crossbars typically made of flat steel or steel rebar with diameters of 10mm or 12mm.

2. Heavy-duty steel grating applications:

Heavy-duty steel grating is designed and manufactured for applications requiring heavy loads, suitable for airports, highways, industrial platforms, ports, and docks, as well as other special demand scenarios.

3. Heavy-duty steel grating categories:

4. Heavy-duty steel grating can be divided into two types according to the production process: heavy-duty welded steel grating and heavy-duty riveted steel grating.

A. Heavy-duty welded steel grating refers to grating with steel bars as cross bars, suitable for unidirectional loading conditions.

B. Heavy-duty press-locked steel grating refers to grating with flat steel bars, suitable for bidirectional loading. However, it is significantly more expensive than welded steel grating and is generally not recommended for use.

C. Surface shape can be divided into flat heavy-duty steel grating and toothed heavy-duty steel grating.

Due to cost considerations, we recommend using flat steel grating in most cases, and heavy-duty toothed steel grating for anti-slip applications such as offshore drilling platforms.

Composite steel grating

This product is composed of steel grating with certain cross-bearing capacity and patterned boards with a sealed surface. After the composite steel grating is heat galvanized, it may exhibit warping and deformation due to heat, especially with larger-sized steel grating, which can be challenging to flatten. Please pay attention to the selection of the type. The composite steel grating commonly uses Series 3 steel grating as the base, but Series 1 or Series 2 steel gratings can also be used. Patterned steel grating typically uses 3mm thick plates, but 4mm, 5mm, or 6mm plates can also be employed. The front or back surface of the composite steel grating can be焊接 with steel mesh to form a double-layered board, which can prevent small items from falling out. The double-layered board is suitable for use in grain silos, restaurants, and warehouses to prevent the entry of mice and other small animals.

Composite Steel Grating Installation Method: Directly weld the steel grating or tread plate to the supporting steel structure, and apply two coats of zinc-rich paint at the welding joints. Use steel grating installation clamps for assembly, which do not damage the galvanized layer and are easy to disassemble. Each set of installation clamps includes one top clamp, one bottom clamp, one M8 round head bolt, and one nut. Stainless steel installation clamps or bolt connection methods can be provided upon request. The typical installation gap for steel grating is 100mm. Ensure the installation is secure and reliable, and regularly check to prevent clamps from loosening or falling off. It is recommended to weld or add rubber pads to the steel grating near vibration sources.

Platform Steel Grating

Platform steel grating is a widely applicable steel grating product, mainly used in various platforms across factories, workshops, mining areas, and ports. It boasts an elegant and imposing appearance, easy installation, and is a new generation building product for replacement.

Platform specialty products include: steel grating plates.

1. Kick plates (end plates), patterned board guards, and mounting accessories can be additional welded around the steel grating edges.

2. Utilize flanges of different specifications than those of the steel grating's flat steel, or use angle iron, channel steel, square tubes, etc., for edging.

3. Handles and hinges can be installed on the platform steel grating panels for frequent movement or opening.

4. Generally speaking: The welding standard for the edge of the platform steel grating panels is as follows: Series 1 - weld every five panels; Series 2 - weld every four panels; Series 3 - weld every three panels. The welds are single-sided angle welds of not less than 3mm, with a length of 20mm.

Stainless Steel Grating

Also known as stainless steel grating panels. There are usually two methods of production: one involves welding together stainless steel flat bars and round bars; the other involves interlocking stainless steel flat bars. They offer strong corrosion resistance, a clean appearance, and a very ideal decorative effect, though they are generally more expensive.

Stainless Steel Grating Categories:

It can be categorized into flat, toothed, and I-shaped types, with over 200 specifications and varieties (the surface can be protected differently depending on the application environment).

Material: Generally, stainless steel grades such as 304, 316, 316L are selected.

Manufacturing Method:

There are two types: machine welding and handcrafted. Machine welding uses a high-pressure resistance welding machine, where a robotic arm automatically places the crossbar horizontally on uniformly arranged flat steel bars, then welds it into the flat steel using strong electric welding power and hydraulic pressure, resulting in a high-quality steel grating with strong weld points, excellent stability, and high strength. Handcrafted steel gratings are first punched with holes in the flat steel, then the crossbar is inserted into the holes and spot-welded. There will be gaps between the crossbar and the flat steel, but each contact point is焊接, achieving an equivalent melting connection between the flat steel and the twisted steel, making the welding more solid and slightly increasing the strength, although the appearance is not as aesthetically pleasing as that of the machine-welded version!

Surface Treatment:

After pickling and passivation, the surface appears as a matte grayish white.

b. Electrochemical polishing results in a brighter surface with higher gloss.

c. The finished products are heat-treated and polished, followed by electrochemical polishing, and then chrome-plated to achieve a mirror-like finish.

Advantages:

Lightweight, high strength, high load-bearing capacity, cost-effective, well-ventilated and light-transmitting, modern style, aesthetically pleasing, anti-slip, easy to clean, and simple to install.

Usage:

Stainless steel grating panels are widely used in power plants, chemical factories, oil refineries, steel mills, machinery manufacturing plants, shipyards, paper mills, cement plants, food processing plants, and bridge engineering, municipal engineering projects, and wastewater treatment facilities where corrosion resistance is critical. The selection of stainless steel grating panels is similar to that of carbon steel grating panels. Due to their unique properties, stainless steel grating panels are extensively applied in various factories both domestically and internationally.

Stainless Steel Grating Covers

Stainless steel channel grating, also known as stair tread plate, steel stair tread plate, or tread plate, is a type of stairboard used on platforms. It can be installed via welding or bolt connections. Welded tread plates can be directly welded to the stair beam.

Overview

Welded fixed tread plates, directly welded to the ladder beam; no need for additional side plates for the tread plates, more economical but not easily removable. Tread plates secured with bolts require thicker side plates, with holes pre-drilled for direct bolt installation, allowing for reuse and recycling. Customers can customize according to their specific needs, using suitable steel grating to create various sizes to match the corresponding staircase.

Features & Applications

(1) The installation of the step board is extremely simple and does not require complex assembly.

(2) Excellent ventilation, lighting, heat dissipation, explosion-proof, and anti-slip properties.

(3) High strength, lightweight structure, and durable tread plates.

(4) Extremely easy to maintain and resistant to dirt accumulation.

Tread plates are widely used in platforms and walkways of factories such as power plants and water treatment plants, as well as in municipal and environmental protection engineering projects. They are also extensively applied to large-scale ground platforms in theaters, visitor platforms, and parking lots.

Grating panel

Grating panels are steel products formed by crossing flat steel bars at a certain spacing with crossbars, welded together to create a square grid pattern in the middle. They are primarily used for drain covers, steel structure platform panels, and steps for steel ladders, etc. The crossbars are typically made of twisted square steel.

Grating panels are typically made of Q235 low-carbon steel, with a hot-dipped galvanized finish to prevent oxidation. Stainless steel can also be used. Steel grating panels offer ventilation, lighting, heat dissipation, anti-slip, and explosion-proof properties.

Manufacturing Methods of Grating Plates: There are two methods, machine press welding and handcrafted. Machine press welding utilizes a high-pressure resistance welding machine, where a robotic arm automatically places the crossbars across evenly spaced flat steel bars, then welds them in place using powerful electric welding power and hydraulic pressure, resulting in high-quality grating plates with strong weld points, excellent stability, and enhanced strength. Handcrafted grating plates are first punched with holes in the flat steel bars, then the crossbars are inserted into the holes and spot-welded. There will be gaps between the crossbars and the flat steel, and it's impossible to weld every contact point, so the welding is not as secure, and the strength is somewhat reduced.

Grille panel features:

1. High strength, lightweight structure: The sturdy grid weld structure provides high load-bearing capacity and a light structure.

2. Features such as easy hoisting;

3. Attractive appearance and durable: Hot-dipped galvanized surface treatment provides excellent corrosion resistance.

4. Attractive surface luster.

5. Good ventilation, lighting, heat dissipation, explosion-proof, and anti-slip performance; resistant to dirt accumulation.

Grating panels are widely used in various industries such as petrochemicals, municipal engineering, port engineering, machinery industry, power and water plants, iron and steel industry, manufacturing, and food processing.

Connector steel grating

Interlocking Steel Grating: Also known as Insert-type Steel Grating, it is manufactured through processes such as slotting (punching), insertion, welding, and finishing, using flat steel, stainless steel, brass, and aluminum plates of specific dimensions. The Interlocking Steel Grating combines the high strength, corrosion resistance, and maintenance-free features of ordinary steel grating, with a uniform structure that is lightweight, exquisite, natural, harmonious, and elegant. This product is widely used for channel covers, stair treads, and pond covers.

Category:

Interlocking steel grating types can be divided into four categories: Interlocking steel grating classification: Differing by insertion method and angle, they include pressed steel grating, heavy-duty steel grating, solid steel grating, and sunshade curtain steel grating, etc.

1. Pressed Steel Grating: After cutting slots in the bearing flat steel, the crossbar flat steel is pressed and locked into shape. Generally, the large processing height for standard steel grating production is 100mm. The length of the steel grating is usually less than 2000mm.

2. Heavy-duty steel grating is a product formed by interlocking high-width steel bars with cross bars under 1200 tons of pressure. It is suitable for high-span load-bearing applications.

3. Integrated Steel Grating Panels - The load-bearing flat bars and cross bars of the integrated steel grating panels have the same height and slot depth, which is half the depth of the load-bearing flat bars. The height of the steel grating does not exceed 100mm. The length of the steel grating is usually less than 2000mm.

4. Sunshade Grating: The load-bearing flat steel of the sunshade grating has 30° or 45° grooves, and the groove bars are formed by pressing and locking. We can deliver grating panels with different spacings and specifications according to your needs, using materials such as carbon steel, stainless steel, aluminum, etc. The height of the grating panels is less than 100mm.

Features: The steel grating features robust weld points, uniform hole spacing, flat surface, attractive design, practical and lightweight, high strength corrosion resistance, and maintenance-free, among many other characteristics.

Application: Widely used in civil and commercial buildings, theaters, subways, urban rail projects, and other municipal engineering fields. Suitable for ceiling, indoor and outdoor decoration, platforms, ventilation windows (wells), billboards, various covers, etc. The interlocking grating panels have firm welding points, uniform hole spacing, and a flat surface, with an aesthetically pleasing and practical design. They are both utility items and works of art. Over the years, more than a hundred varieties have been developed, and sixteen exported products are particularly favored by customers.
