Product NameGlass-Fiber Reinforced Plastic Desulfurization Tower
Product IntroductionThis equipment is primarily used for烟气治理 in industrial coal-fired, oil-fired, and biomass boiler and furnace applications. Made of high-temperature-resistant fiberglass resin, it employs the gas-liquid countercurrent contact principle to utilize an alkaline circulating water solution for washing and neutralizing dust in the flue gas. It effectively resolves the issues of traditional granite dust collectors, such as air leakage and long construction periods, as well as the corrosion resistance problem of carbon steel equipment.
Core Features
- Corrosion-resistant and high-temperature resistant:For its characteristics of high temperature and strong corrosiveness, the inner wall of the tower is made of a special high-temperature and wear-resistant resin material. Under the long-term influence of acidic gases and high-temperature environments, it still maintains structural stability, thereby extending the service life of the equipment.
- Desulfurization and dust removal integrated system:The internal structure design of the equipment is scientific, integrating desulfurization, dedusting, and dehydration functions. After flue gas enters the tower, it passes through multiple spray and filling layers, which increases the gas-liquid contact area, resulting in more thorough waste gas purification and meeting environmental protection emission requirements.
- Low running resistance, low energy consumption:Optimized fluid dynamics design ensures even airflow distribution, reducing system resistance and thereby decreasing the electric consumption of the fan, resulting in cost savings in operation.
- Scale-free, clog-resistant:Utilizing large flow nozzles and a scientifically designed internal spray arrangement, dead corners are minimized, effectively preventing dust and reaction by-products from settling and scaling inside the tower, thereby reducing the frequency of shutdowns for cleaning.
【Application Range】
- Boiler accessories:Coal-fired boiler, biomass boiler, and oil-fired boiler exhaust treatment.
- Industrial Kilns:Flue gas purification for brick, ceramic, and glass kilns.
- Metallurgy Industry:Sulfur-containing flue gas treatment from smelting furnaces, sintering machines, etc.
Customization InstructionsWe offer fromCondition analysis, scheme design, equipment manufacturing to on-site installationOur services include customizing vertical or horizontal desulfurization towers based on your boiler tonnage, exhaust gas temperature, and site limitations. We also offer guidance in selecting配套 circulating water pools, pumps, and fans.
