Product Introduction
The DY-YLB Digital Pressure Gauge is ideal for both field and laboratory use, catering to pressure measurement and the calibration of general pressure gauges, pressure indicators, digital pressure gauges, and analog pressure gauges. It can fully replace analog pressure gauges.
• Main Parameters: -0.1~60 MPa, gauge pressure, absolute pressure, available in multiple specifications including 0.2%, 0.1%, 0.05% FS, 0.02% FS, etc.
• Main Applications: Pressure measurement, calibration of general digital pressure gauges, and serves as an ideal alternative to pointer-type pressure gauges.
Key Features
1. High precision, high reliability
2. Auto-zeroing function
3. Micro-power consumption technology, continuously operating for over 10,000 hours without standby mode
4. Auto Peak Value Recording
5. Switch between various pressure units: mmH2O, mmHg, inH2O, Pa, kPa, MPa, psi, bar, mbar
6. Measurement Speed: Fast - 3 times/second (default), Slow - 1 time every 10 seconds, adjustable speed
7. Display: White backlit, 6-digit display, decimal point position adjustable.
8. Power Supply: Built-in 1 piece LS14500 3.6V lithium battery or 3 pieces of AA alkaline South孚 batteries, with an option for an external adapter.
