The Y2-航空插头 is a replacement for the old "P" type electrical connector (aviation plug), featuring small size, light weight, ease of use, durability, excellent conductivity, and good socket sealing. Wall-through sockets are convenient for connecting both ends, easy to disassemble, and widely used for wiring connections between various electrical equipment, instruments, and meters.

Environmental Technology Performance

Operating Temperature: Welded Type -55℃ to 125℃, Soldered Type -55℃ to 200℃

Relative humidity: 95% at 40℃

Working Height: 30,000m above sea level

Vibration: Frequency 10Hz - 2000Hz, Acceleration 147 m/s²

Impact: Acceleration 490 m/s²

Constant Acceleration: 490 m/s²

Airtightness: Resistant to pressure of 0.2Mpa (only for sealed socket)
