Product Description
The high-precision refrigeration恒温槽 is primarily composed of a refrigeration system, heating system, temperature control system, and stirring system. The tank is divided into a mixing area and a working area. In the mixing area, the cooling generated by the refrigeration system cools the liquid (medium) inside the tank through an evaporator. The temperature control system then adjusts the heater based on the temperature readings from sensors. After that, the liquid (medium) is thoroughly and evenly mixed by the stirring system and sent to the working area, which is minimally affected by external disturbances. This results in a liquid space with stable temperature and uniform temperature field.
Product Features
The DY-RTS80 Refrigerating Constant Temperature Bath (-80℃ to 105℃) is a high-precision automatic temperature calibration equipment with high temperature control accuracy, uniform temperature field, good stability, easy operation, and uses a fully enclosed compressor refrigeration system. Both the outer shell and inner tank are made of full stainless steel material. The product is used by metrological departments for first and second-class standard thermometers, and Beckman thermometers. It is also used for industrial platinum resistance thermometers and standard copper-constantan thermocouples. It can serve as a high-precision heat and cold source for production and scientific research. The Refrigerating Constant Temperature Bath is a high-precision automatic digital temperature calibration device, featuring good temperature stability, uniform temperature field, and high temperature control accuracy. The refrigeration system uses a fully enclosed refrigeration unit, characterized by low noise, high reliability, and long lifespan. The digital temperature controller achieves automatic temperature control according to the PID control law, with a compact structure, easy operation, and direct reading of the bath temperature. It is suitable for various metrological, biochemical, petroleum, meteorological, energy, environmental protection, and pharmaceutical departments, as well as manufacturers of thermometers and temperature controllers, for the detection of physical parameters, and can provide a constant temperature source for other experimental research work.
Note: 1. The above products can also be equipped with RS-232 or 485 communication interfaces upon request, for user terminal connection.
2. The product meets the requirements of the JJF 2019-2022 specification for temperature performance testing of liquid constant-temperature test equipment, including both ramp-up and ramp-down temperature requirements.
