The company reserves the right to make improvements and changes to the product's appearance and technical specifications without prior notice; the products and images are for reference only, and the actual product appearance prevails. For detailed product information, please contact our company.

Product Model

Model: NS70128-T

Keyword: 128 Channel Streaming Media Terminal

Product Overview

Engineered for video remote surveillance, deployed at the edge where remote monitoring is required, it supports network penetration networking and adapts to various network architectures, allowing for easy implementation of video internet remote monitoring without reliance on other dedicated network devices.

Product Features

• The system employs an embedded architecture design.
• Supports a wide range of popular IPC/DVR/DVS/NVR video equipment from various manufacturers, including Hikvision, Dahua, Uniview, Tiandy, and more.
• All equipment can be accessed via standard protocols such as ONVIF and RTSP.
• Local access via H5, RTSP, SDK, and other methods.
• Supports real-time monitoring, remote control, video search, and playback functions, as well as multi-channel concurrent access.
• Deployable in various network environments including LAN, WAN, and the Internet, ensuring worry-free data transmission.
• Easy to deploy; simply configure the IP address correctly to establish communication and access.
• Signal channel data encryption ensures the security of internet data transmission.
• 24/7 continuous operation, high stability.
• Supports network self-inspection and automatic repair of disconnections.
• Remote maintenance support for equipment.

Technical Specifications

• Networking Capability: Equipped with an integrated RSLink device networking protocol, featuring remote monitoring and management capabilities.
• Connectivity: Compatible with video devices via RTSP, ONVIF, or proprietary protocols from major manufacturers like Hikvision, Dahua, and Uniview.
• Interface Protocols: H5, RTSP, WS, SDK, HTTP, etc.
• External Interfaces: 2 RJ45 10/100/1000Mbps auto-negotiating network ports, 1 HDMI, 2 USB ports
• Power Supply: DC 12V
• Power Consumption: 20W to 100W
• Operating Temperature: -20℃ to +60℃.
