The company reserves the right to make improvements and modifications to the product's appearance and technical specifications without prior notice; the products and images are for reference only, and the actual product appearance shall prevail. For detailed product information, please contact our company.
Product Model
Model: NS7016-T
Keyword: 16-way Streaming Terminal
Product Overview
Specifically designed for video remote monitoring, deployed at the edge where remote monitoring is required, it supports network penetration and network architecture adaptation. It can easily implement video internet remote monitoring without relying on other dedicated network devices.
Product Features
- The system features an embedded architecture design.
- Supports a wide range of mainstream IPC/DVR/DVS/NVR video equipment, compatible with brands like Hikvision, Dahua, Uniview, and Tiandy.
- All equipment can be accessed via standard protocols such as ONVIF and RTSP.
- Achieve localized access through H5, RTSP, SDK, and other methods.
- Supports real-time monitoring, remote control, video search, and playback functions, as well as multi-stream concurrent access.
- Deployable on local area networks, wide area networks, the internet, and various network environments, with worry-free data transmission.
- Easy to deploy; simply configure the IP address correctly to establish communication and access.
- Signal channel data encryption ensures secure internet data transmission.
- 24/7 continuous operation, high stability.
- Supports network self-inspection and automatic recovery after disconnection.
- Remote maintenance support for equipment.
Technical Specifications
- Integrated RSLink device networking protocol with remote monitoring and management capabilities.
- Access Capabilities: Connect video equipment via RTSP, ONVIF, or private protocols from mainstream manufacturers such as Hikvision, Dahua, and Uniview.
- Interface Protocols: H5, RTSP, WS, SDK, HTTP, etc.
- External Interfaces: 2 RJ45 10/100/1000Mbps auto-sensing network ports, 1 HDMI, 2 USB
- Power Supply: DC 12V
- Power Consumption: 5W to 30W
- Operating Temperature: -20℃ to +60℃.
