Product Overview:
Application: Gas pressure regulating (metering) cabinets (stations) are used for high and medium pressure; medium and low pressure gas transmission and distribution, serving as regional, commercial users, direct-firing engines, gas boilers, and other gas pressure regulating gas supply; suitable forNatural GasGas, LiquefiedPetroleum & GasAnd other non-corrosive gases.
Main Configuration:
Valves for import/export, gas filters, safety cut-off valves, gas regulators, safety relief valves, metering instruments, controllers, piping, and more.
Product Features:
One. Integrated pressure regulation (metering), filtration, safety cut-off, and safe venting.
2. The pressure-reducing box has a simple structure and is easy to maintain.
3. All products undergo rigorous leak and performance tests prior to shipment to ensure safe gas supply to customers.
Four. The pressure regulating cabinet is made of materials such as steel plate electrostatic coating, glass fiber reinforced plastic, composite color steel plate, and stainless steel plate.
V. Customized pressure regulating boxes according to customer requirements are available.
Primary Structure Form:
1+0 (Full Pressure Reduction)
1+1 (Through-pressure Control with Bypass)
2+1 (one unit operational and one in reserve)
2+1 (one main and one standby with bypass)
Installation and Usage:
The pressure regulating box should be installed on the ground. It should be gently lifted and placed during installation; it must not be tilted or inverted.
2. When connecting import and export, install the regulator in the direction of the airflow, do not reverse it. The flanges must be parallel, do not force them into place.
3. Upon completion of installation, a gas-tightness test should be conducted to ensure the tightness of the connections at the inlets and outlets.
4. Pressure regulating box gas-tightness test on the export side shall not exceed its closing pressure.
5. The installation distance of the pressure regulating box should comply with standard requirements.
