Floating Tube Heat Exchanger

A floating tube bundle heat exchanger is a type of indirect heat exchanger, The heat transfer section is made of copper tubes., Helically coiled heat exchanger tubes are floated inside the shell., So it is called a floating tube bundle. The heat transfer tubes of this heat exchanger are inside the shell., High-frequency vibration that can float up and down when water flows through, Cause the heated water to become turbulent, Therefore, it enhances the heat transfer efficiency and can automatically descale, reducing limescale. The floating tube heat exchanger is a typical equipment in the domestic centralized hot water supply system in China in recent years.

It can be divided into floating tube volume heat exchangers and floating tube semi-immediate heat exchangers.

Among the floating tube volume heat exchangers, they are categorized into horizontal and vertical types based on the placement of the tank. According to their arrangement within the heat exchanger, they are further divided into horizontal floating tubes and vertical placements (with the vertical type further subdivided into top-mounted and bottom-mounted).

Application Scope:

Floating tube heat exchangers are widely used in industrial and civil buildings such as chemical engineering, oil refining, shipbuilding, and in high-end hotels, restaurants, office buildings, school research buildings, outpatient and inpatient wards, etc., for heating, air conditioning, and hot water supply systems, including boiler rooms, heat exchange stations, and air conditioning rooms as heat exchange equipment.
