High-output PF, 0.9 PF

High power density, capable of handling more loads

0.99 input PF

Lower input harmonic, THDi < 5%, energy-saving and environmentally friendly

1% output voltage accuracy, 0.1% output frequency accuracy, 1% parallel current balancing, stable and reliable output performance

• Inverter efficiency 94%, ECO mode efficiency 98%

At 30% load, efficiency reaches 93.5%, offering high energy savings and efficiency.

Battery cell count adjustable

Adjustable between 16/18/20 cells, for extended discharge time and lower system costs.

Intelligent charging management technology, extends battery life

3-segment charging

Battery self-detection

•  Comprehensive Charging Protection

Input topology adjustable

Supports three-phase input, also supports single-phase input, flexible configuration

Comprehensive communication card options, easy to manage

Advanced parallel technology

• Mature and stable parallel control technology ensures uniform current distribution: 1%

• Select trip technology effectively isolates single-point failures in the isolation system, further enhancing system availability

Flexible expansion and redundancy management to meet various post-extension needs

• Parallel units up to 3 sets

Flexible Electricity Usage Strategy

• Online mode offers high system availability

•  Efficient mode offers an economical operating method

• VFD mode provides a stable output
