Performance Features

Utilizing a 7-inch TFT wide-screen display (800*480) with 65k color settings and test parameters, the displayed content is clear and rich.

The front panel features two USB ports, which can be used for USB drive storage or connected to a barcode scanner.

The tester can automatically save the test results in the format of an EXCEL spreadsheet to a USB drive.

Software upgrades can be performed via a USB drive.

Leakage current test for human body network meets relevant standards.

Leakage current offers four detection methods: AC, AC+DC, PEAK, and DC.

The theme background of the tester can be set via the software.

Leakage testing can measure the MD terminal voltage without the need for an external voltmeter, meeting the relevant testing requirements.

Leakage test can display the switching status of each switch and the human body network under test.

Leak executable for single fault testing.

Leakage tests can be performed with polarity reversal without cutting off the power supply.

Leakage tests provide auxiliary power required for testing, meeting the requirement of a small leakage current of 10uA.

The high-voltage indicator light is not controlled by the main controller and directly indicates the voltage level of the output port, with a rapid voltage rise time (within 100ms).

Measure the automatic stability control system.

Standard with PLC interface, optional RS232, RS485 interfaces.

Applicable Standards: GB9706.1-2007 (IEC60601-1), GB4793.1-2007 (IEC61010-1).
