Performance Features

Equipped with a safety electrical wall, it can automatically detect if the input power is correct.

Output is variable frequency at high voltage, ranging from 40Hz to 400Hz.

After the DC withstand voltage and insulation resistance tests are completed, the tester can quickly discharge within 0.2 seconds, ensuring the safety of the operator.

Features a low current alarm function to prevent misjudgment caused by open circuit of the test wire during testing. The output voltage has upper and lower voltage limit alarm functions.

Features keyboard lock function to prevent operators from modifying test parameters, ensuring the test subject is tested according to the set parameters.

The linear power amplifier drives an output sine wave voltage (current) with a peak factor ranging from 1.3 to 1.5.

Equipped with a 240*64 graphic LCD display and user-friendly interface design.

Features both Chinese and English display interfaces, catering to the diverse needs of various users.

The programmable high-voltage unit features an oscilloscope interface, enabling monitoring of the ignition, arc, and corona discharge phenomena of the tested object.

Pre-set and save test parameters: Up to 30 files can be set, with each file accommodating 99 test steps.

Optional RS232, RS485, USB, standard PLC interface.
