In the LED display industry, the power distribution cabinet, as one of the core components, directly impacts the stability and lifespan of the display due to the high current surge during startup. Since LED displays are powered by a large number of switching power supplies, they can easily cause a surge in the power grid. Therefore, for displays with power over 10KW, it is recommended to use a dedicated intelligent power distribution cabinet for LED displays.

This product features an indoor shell with a total load power of 10KW, capable of connecting three single-phase electrical equipment circuits (such as display loop, air conditioning loop, and fan loop). It offers overcurrent and short-circuit protection, manual power on/off, and PLC power on/off functions. The standard circuit breaker is a Delixi product, while the contactor is a Schneider product. The PLC power supply utilizes a high-reliability industrial-grade product from Mervic, and the controller is an Omron/IPMS/Siemens PLC product. It is equipped with RS232/TCP/IP communication, allowing integration into a central control system for联动 control. It facilitates quick and convenient external data monitoring of the LED display system and remote intelligent power control. The system is based on the B/S architecture and is compatible with multiple platforms, including Windows, Linux, Android, Hongmeng, and Kylin, among others.

• Features

1.All models feature dual protection; the input circuit breaker is a molded case circuit breaker, and the output circuit breaker is a miniature circuit breaker. 2. It supports PLC remote real-time monitoring and management of the power system.

3.Manual, PLC remote, timed automatic control on, power off

4.Standard with overcurrent and short-circuit protection

5.Different color indicator lights differentiate the phase line power input conditions.

6.Manual, Stop, Auto, three-speed panel control switch.

7.All critical components are made with internationally renowned brand components; all cables are selected with national standard copper cables, and all cables are terminated with purple copper terminals, with each cable having a 20% or more safety margin in the box.

8. Products are designed and manufactured in accordance with national standards, featuring unique reinforcement in the shell design and using sheet metal with a thickness of 1.2mm or more, coated with plastic.

9. All systems are pre-set with various plans. When used online, they allow for remote monitoring of the power cabinet's status. When used offline, they can automatically execute the联动 logic of the plans.

10．All models come standard with circuit breakers and lighting control loops in the repair sockets.

11.The system is cross-platform compatible and supports Windows, Linux, Android, HarmonyOS, Kylin, and more operating systems.

• Technical Specifications

• Application

Command center, conference rooms, multi-functional halls, exhibition halls, etc., powered by LED screens.

• After-Sales Service

1One-year free warranty, lifetime technical support.

• Packaging

Standard cardboard box packaging.

• Utilize Information

Please read the product user manual thoroughly before use.

• Cautionary Notes

This product contains high voltage; it must be terminated and maintained by a technician with professional electrical qualifications.
