In the LED display industry, as one of the core components, our company has launched a new intelligent power distribution system specifically designed for LED displays, catering to compact server room spaces without available installation areas and high-end application environments such as conference rooms and command centers.
This system utilizes a 19-inch standard rackmount design, which can be easily mounted in a cabinet, featuring an aesthetically pleasing appearance. It offers remote control capabilities, allowing for the operation of the LED display and internal equipment such as air conditioners and fans via PC software. It also enables real-time monitoring of the internal environment temperature and fire conditions, with corresponding alarm notifications.
Embedded LED display screens with an intelligent power management system are an integrated management platform for quickly and conveniently monitoring application environment data and controlling power supply for displays. Featuring a high-speed processor, this core processor provides the required high performance and reliability for industrial and embedded control applications. It aids in quickly and conveniently monitoring external data of the LED display system and remotely controlling the power supply intelligently, offering robust and reliable protection to the system.
Key Features
1. Features overcurrent protection, short-circuit protection, optional fire alarm protection, electrical box over-temperature protection, and display screen over-temperature interlock protection functions.
2. The system can achieve automatic step-by-step delayed power-on, effectively reducing the surge current during power-on. It supports one-click full power-off and can also control individual channels separately.
3. Comes with a matching PC control software, enabling remote control of power on/off, allows for setting up to 8 groups of timed power on/off tasks, and can view operation logs.
4. Operators can directly operate the buttons on the equipment panel to activate or deactivate the one-touch start and stop buttons.
5. The Open Control Protocol is controlled by the central control device, supporting RS232, RS485, and TCP/IP communication.
6. Utilizes 5-port power input, 6-way 20A industrial socket plug main output, and 2-way standard socket auxiliary output; wiring can be completed without opening the electrical box.
(7) Features a 6-channel bypass switch, allowing for the shutdown of power to the display screen even when the equipment malfunctions, ensuring the ability to power or shut off the screen at any time. (This feature is for emergency use only and is not a routine function.)
Technical Specifications
Rated Capacity | 10KW |
Output Circuit | 3Single-phase circuit |
Number of Output Channels | Three-channel |
Input/Output Voltage | Input 3-phase 5-wire system 380V, output single-phase 220V |
Rated Output Power per Channel | ≤3.33KW |
Operation Mode | Manual, Standalone Automatic Control, Online Synchronous Remote Control |
Short circuit and overload protection | Available |
Step-by-step, graded power-on delay | Available |
Schedule task to turn on/off power | 8Group timing switch Each channel can be set to different times depending on the load equipment (such as screens, air conditioners, computers, audio systems), supporting daily and weekly settings. |
Remote power-on | Available |
Central Control System | Available |
Communication Methods | TCP/IPNetwork/RS232/RS485 |
Wiring method | Aviation connector rear input wire |
Rapid Disconnect Power Plug | Available |
Auxiliary inspection lighting socket | Available |
Temperature Detection | Available |
Humidity Detection | Available |
Emergency power restoration | Available |
Access Management | Available |
Alarm Input | 5Channel |
Smoke Detector | Available (Optional) |
Fire Alarm Power Failure Function | Available (optional) |
Over-temperature shutdown function for electrical box | Available (optional) |
Display Overtemperature Interlock Function | Available (optional) |
Shell Size | Standard 19-inch rackmount with 2.5U height, 440mm x 400mm x 110mm |
· Usage
Command centers, conference rooms, multi-functional halls, exhibition spaces... etc., powered by LED screens.
· After-sales service
1One-year free warranty, lifetime technical support.
· Packaging
Standard cardboard box packaging.
· Utilize Information
Always read the product manual thoroughly before use.
· Cautionary Notes
This product contains high voltage; it must be terminated and maintained by a technician with professional electrical qualifications.
