Operating Principle:
Compressed air, after being chilled, filtered, and dried, is then directed through nozzles to form supersonic airflow into the crushing chamber. This causes the material to become fluidized. The accelerated material converges at the intersection of multiple nozzles' jet streams, resulting in intense collisions, friction, and shearing, thereby achieving ultra-fine particle crushing. The crushed material is then transported to the impeller classification area by an upward airflow. Under the influence of the centrifugal force from the classification wheel and the suction force of the fan, coarse and fine powders are separated. The coarse powder returns to the crushing chamber under its own gravity for further crushing, while the qualified fine powder is carried by the airflow into the cyclone collector. Fine dust is collected by a bag dust collector, and the purified gas is exhausted by a blower.
Features:
1. Low energy consumption, compared to traditional fluidized bedAirflow PulverizerCompared, it can save energy by 30%.
2. Built-in self-diverting micro-powder systemGrading machineThe particle size distribution is concentrated, with no oversized particles in the finished product.
3. The equipment has a compact structure and occupies a small area.
4. The crushing box is free of leftover materials and blind spots, making it easy to disassemble, clean, and disinfect. It is convenient to switch between different varieties and meets GMP requirements.
5. Low-temperature, medium-free crushing, particularly suitable for the crushing of materials with low flame points, heat sensitivity, sugar content, and volatile substances.
6. For flammable and explosive materials, full-sealed crushing can be achieved using inert gases as the medium, with the inert gases being recycled for extremely low loss.
7. Wide crushing particle size range, finished product particle size adjustable from 0.5 to 45 um; full range of machine models available, with production capacities from 5 to 3000 kg/h, options to choose from.
8. Vacuum production, free of dust pollution, with excellent environmental conditions.
High level of automation, strong stability, and easy operation.
