Application Range:

 SCWNHorizontal screw blade mixer is used in applications such as pesticides, veterinary drugs, food, chemicals, biology, aquaculture, ceramics, refractory materials, plastics, and compound fertilizers, etc.-Solid (i.e., powder to powder)-Blending of pulp (i.e., powder and paste liquid), particularly suitable for thick material mixing.

Performance Features:

   ①SCWNThe horizontal screw blade mixer operates independently of particle size and density under feasibility factors.

② Excellent mixing effect on sticky materials.

③ The smooth mixing process minimizes damage to fragile materials, and the addition of a knife structure also aids in crushing.

④ Horizontal structure with lower machine height for easy installation.

⑤ The male and female helical blades are installed on the same horizontal axis, creating a low-power, high-efficiency mixing environment.

Operating Principle:

   ①SCWNHorizontal screw blade mixer drives the material in the drum with the help of the inner and outer diameter screws mounted on the stirrer shaft, causing the stirrer to flip the material over a larger area within the drum.

② The agitator is structured with helical design that is mutually counter-rotating in the inner and outer, as well as left and right directions. When the agitator operates, the inner helix drives the material near the axis to rotate around the axis, pushing axially from the inside to the sides. The outer helix drives the material near the drum wall to rotate around the axis, pushing axially from the sides to the inside. This creates a convectional circulation, shearing, and mixing of materials within the drum, achieving a rapid and even mixing of the material in a short period of time.
