Detailed Description:
Operating Principle:
Compressed air is chilled, filtered, and dried before being directed through nozzles to form supersonic airflow into the crushing chamber. This converts the material into a flowing state. Accelerated material converges at the intersection of multiple jet streams, resulting in intense collisions, friction, and shearing for ultra-fine particle crushing. The crushed material is then transported by ascending air currents to the impeller classification area. Under the centrifugal force of the classification wheel and the suction force of the fan, coarse and fine powders are separated. The coarse powder returns to the crushing chamber due to gravity for further crushing, while qualified fine powder is carried by the air flow into the cyclone collector. The ultra-fine dust is collected by a bag dust collector, and the purified gas is exhausted by a blower.
Features:
Low energy consumption, compared to traditional fluidized bedAirflow PulverizerCompared to others, it saves up to 30% in energy.
2. Integrated self-flowing microfine powderGrading machineThe particle size distribution is concentrated, with no excessively large particles in the finished product.
3. The equipment has a compact structure and occupies a small area.
4. The crushing box is free of leftover materials and blind spots, making it easy to disassemble, clean, and disinfect. It is convenient to switch between different varieties and meets GMP requirements.
5. Low-temperature, medium-free crushing, especially suitable for materials with low flame points, heat sensitivity, sugar content, and volatile substances.
6. Flammable and explosive materials can be fully enclosed crushed using inert gas as the medium, with the inert gas being recycled for extremely low loss.
7. Wide range of particle size, finished product particle size adjustable from 0.5 to 45 um; full range of models available, with production capacity ranging from 5 to 3000 kg/h.
8. Vacuum production with zero dust pollution, ensuring an excellent environment.
High level of automation, strong stability, and easy operation.
