Product Introduction

High-throughput tissue homogenizers are used for pre-treatment of biological samples. Large-scale, automated rapid extraction of genomes utilizes a high-speed oscillating collision vibration mode through high-frequency reciprocating vibration, impact, and collision using grinding beads (zirconia beads, steel beads, glass beads, ceramic beads).

Quick shearing for fast realization of the goal.

Application Scope

1. Suitable for grinding and crushing samples of various plant tissues, including roots, stems, leaves, flowers, fruits, and seeds.

2. Suitable for grinding and crushing samples from various animal tissues, including brain, heart, lung, stomach, liver, thymus, kidney, intestines, lymph nodes, muscle, and bone.

3. Suitable for grinding and crushing samples of fungi, bacteria, etc.

4. Grinding and crushing for food and pharmaceutical ingredient analysis testing.

5. Suitable for grinding and crushing volatile samples such as coal, oil shale, and wax products.

6. Suitable for grinding and crushing samples of plastics, polymers including PE, PS, textiles (yarn), resins, etc.

Product Features

1. Method of Motion: Vertical oscillating pearl grinding and collision.

2. Capable of handling 4x25mL grinding tubes, 12x5-10mL grinding tubes, and 2x50mL grinding tubes; custom sizes available upon request.

3. Compatible sample volume: 4*25mL / 12*(5-15)mL / 2*50mL; custom-made grinding tubes of various specifications available.

4. Touchscreen display with user-friendly interface design, easy to operate; allows for intuitive and convenient operation:

5. Stores ≥ 50 sets of experimental data, with animal heart, spleen, lung, kidney, bone, skin, and hair patterns available for different experimental samples.

6. Multi-stage operation modes with adjustable gaps, allowing for multiple running experiments as set, further reducing human factor interference.

7. Larger raw material dimensions: No specific requirement; adjust according to the adapter.

8. Material Particle Size: ≤5µm; Number of Grinding Platforms (Number of Grinding Jars Acceptable) >2

9. Tension device with automatic centering positioning, featuring a safety lock during operation for full protection.

10. Grinding Methods: Wet Grinding, Dry Grinding, and Low-Temperature Grinding Available

Adapter Material: Alloy Steel

12. Adapters can be easily replaced; over a dozen types are available for selection.

2.0ml x 24 Cryogenic Adapters (up to -196°C), 5.0ml x 12 Cryogenic Adapters (up to -196°C)

15ml x 8 Cryogenic Adapters (up to -196°C), 25ml x 2 Cryogenic Adapters (up to -196°C)

50ml x 2 Cryogenic Adapters (up to -196°C), custom sizes are acceptable.

Technical Specifications

Display: 7-inch touch screen, shows working status, supports programming and storage

Optional adapter flow rates: 4 x 25mL / 12 x 5-10mL / 2 x 50mL

Uniformity speed: 0~70Hz   High speed rotation ≤7000rpm

Grinding Methods: Wet grinding, dry grinding, and low-temperature grinding available

Power: 220V, two-phase / 50Hz

Operating Hours: 0 seconds - 999 minutes, customizable by the user

Ball Mill Diameter: 0.1-30mm

Grinding ball materials: stainless steel, chrome steel, zirconia, tungsten carbide, quartz sand.

Accelerate: Reach high speed within 2 seconds

Deceleration: Achieve low speed within 2 seconds

Noise Level: ≤54 dB
