SINAMICS G120C compact inverter sets a benchmark for the design of similar inverters in many aspects. Its compact size, convenient quick setup, simple panel operation, user-friendly maintenance, and rich integrated functions will become the new standard. Siemens G120 inverter specifications, Siemens G120C inverter price, Siemens G120C inverter
To the top of the pag
SINAMICS G120C – Key Advantages
SINAMICS G120C is a variable frequency inverter designed specifically to meet OEM users' needs for high performance and space-saving. It boasts simple operation and rich features. This series of inverter is smaller in size than similar products with the same power, and it features quick installation, easy tuning, and a user-friendly wiring method, along with simple debugging tools, setting it apart from others. It integrates numerous functions: including Safe Torque Off (STO), available via terminals or PROFIsafe, various optional fieldbus interfaces, and a memory card slot for parameter copying. Siemens G120 inverter parameters, Siemens G120C inverter price, Siemens G120C inverter
The SINAMICS G120C inverter comes in three different size power ranges from 0.55kW to 18.5kW. To enhance energy efficiency, the inverter incorporates vector control for optimized operation and automatically reduces flux. This series of inverters is part of a fully integrated automation system and offers optional communication interfaces such as PROFIBUS, Modbus RTU, CAN, and USS. Operation and debugging can be quickly and easily performed using a PC via the USB interface, or through the BOP-2 (Basic Operation Panel) or IOP (Intelligent Operation Panel).
New Member of the SINAMICS Family
SINAMICS G120C is part of the SINAMICS drive family, which offers comprehensive power and functionality - an innovative drive for the future. The SINAMICS drive family provides a drive solution for every application. Naturally, all inverters can be configured, parameterized, tuned, and operated in the usual manner.
The SINAMICS drive family boasts a range of advantages:
Standard operational controls and features ensure they share the same hardware and software platforms.Covered voltage range for low and medium pressure
All variable-frequency drives utilize the same engineering tools.
——SIZER for engineering design
——STARTER for parameter setting and debugging
High level of versatility and compatibilitySame optionsTraining Fees
Mechanical Design |
Compact |
Simple installation and maintenance |
Can be installed side by side tightly without reducing capacity. |
Removable terminal blocks |
Electrical Design |
Built-in braking unit |
STO Function |
IOP, BOP-2, and USB ports |
Integrated Storage Card (SD) Slot |
Input with electrical isolation |
Communication Function |
■ DP, CAN, USS, Modbus RTU |
Fully integrated automation (TIA) compatible |
Characteristics of G120C | Your benefits | |
|---|---|---|
Compact structure | ||
Can be installed side by side with no capacity reduction Higher power density, smaller dimensions Simpler installation, requiring less space | Less space required Can be installed in smaller cabinets, closer to the installation site | |
User-friendly | ||
Optimized parameter set Optimized debugging Simplified Operation Instructions - Getting Started Guide ■ Available with BOP-2 and IOP control panels Integrated USB Interface | Simple and quick software parameter setup Operation and debugging procedures are simpler. Maximize existing SINAMICS knowledge to reduce training costs ■ Easier and more user-friendly repair | |
Simple installation and maintenance | ||
■ Removable terminal blocks ■ Parameters can be copied via the BOP-2 and IOP control panels, as well as the SD card. The G120C can be remotely debugged via TIA. Variable Frequency Drive and Motor Running Time Counter | Rapid mechanical installation Intuitive series tuning Can be integrated into an automated environment Maintain with greater simplicity | |
High-efficiency, sensorless vector control Automatically reduce flux through V/f ECO function Integrated Energy Calculator Integrated STO feature Integrated communication interfaces (DP, CAN, USS, Modbus RTU) | Higher control accuracy and quality Motor control offers higher energy efficiency. ■ Calculable Energy Savings ■ Includes functionality at no extra cost Can be connected to all standard bus systems | |
Stable and reliable | ||
■ Utilized components suitable for overload conditions. All circuit boards are coated. Operating environment temperature up to 60°C | ■ Operates flawlessly in harsh industrial environments Extended service life |
