HMI for medium-performance tasks, designed for use on PROFINET networks, particularly when paired with SIMATIC S7-1200 controllers and other controllers. The TP1500 meets high requirements in terms of screen size and resolution.

Advantages

Offered at attractive prices with high resolution and suitable screen size.

Fits interfaces of the same size and is compatible with multi-interface products.

Proven SIMATIC Quality

Available in 32 configurable languages for global use (with 5 languages switchable online)

Design and functionality

TP1500 Basic color features a 15-inch TFT display with 256-color capability. The 1024 x 768 pixel resolution allows for complex operational screens to be displayed with appropriate size and color representation. The interface is operable via a resistive touch screen. The TP1500 Basic color is an ideal HMI component for medium to high-end S7-1200 controller systems. It can be configured using the WinCC flexible Compact or the HMI configuration software for S7-1200's STEP7 Basic engineering software. The TP1500 offers basic functionality for 500 variables, including alarms, trend curves, and recipes. We also provide an entry-level software package, which includes the WinCC flexible Compact configuration software, SIMATIC HMI Manual Collection on a DVD, an Ethernet cable, and a certificate for one year of software upgrade services, all with significant price advantages.

Technical Data
