Overview

The GN19-12 series indoor high-voltage disconnectors are high-voltage switchgear designed for use in power systems with rated voltage of 12KV, AC 50Hz and below, and are paired with the CS6-1 manual operation mechanism. They are used for opening and closing circuits when there is voltage but no load. Derivative products with anti-corrosion features are also available.

Highland type and with electric display installed. This series of disconnectors is equipped with the CS6-1 manual operation mechanism. The series disconnectors are three-pole types, consisting of a base frame, pivot shaft, lever, porcelain insulator, blade, and terminal board, etc. The pivot shaft is mounted on the base frame, with three pairs of levers welded onto it, which are connected to the blade chain via rod porcelain insulators. The pivot shaft extends from the base frame, allowing any segment to be connected to the operation mechanism. The C-type is for through-type installation. Among them, C1 indicates rotation on the wall-side, C2 indicates breaking on the low-side, and C3 indicates both sides are on the wall-side.
