Basic Parameters

1. Rating: 50mA, 12VDC

2. Contact Resistance Co.ntact Resistance : 50mΩ max(initial)

3. Insulation Resistance: 100MΩ (min DC 250V)

4. Dielectric Strength: AC 250V (50/60Hz for 1 minute)

5. Electrical Life: 20,000-1,000,000 cycles

6. Environmental Temperaturenment temperature: -25℃-70℃

7. Operating Force: 100/180/230/250/300 (±30gf)

8. Heat Deflection Temperature: 250℃-280℃
