Smart Permanent Magnet Double Mechanism ZW32-12F Watchdog Vacuum Circuit Breaker High Voltage Circuit Breaker
1. Overview:
ZW20-12F Type Outdoor AC Intelligent Boundary Vacuum Circuit Breaker (Watchdog) is an outdoor high-voltage switchgear designed for rated voltage of 12kV, three-phase AC 50Hz. It is mainly used for opening and closing load current, overload current, and short-circuit current in power systems. Suitable for substation, industrial and mining enterprises, and urban and rural power networks for protection and control, especially for frequently operated sites and urban distribution automation networks. Passed the type test by national institutions and meets the following standards: GB1984 High-Voltage AC Circuit Breaker.
GB/T11022 Common Technical Requirements for High-Voltage Switchgear and Control Equipment; D11402 Technical Conditions for Ordering AC High-Voltage Circuit Breakers.
2. Terms of Use:
2.1 Altitude: Not exceeding 1000m.
2.2 Surrounding Air Temperature: -40℃ to +40℃; daily temperature difference: does not exceed 25℃.
2.3 Wind Speed: Not exceeding 34 m/s
2.4 No areas with flammable, explosive hazards, strong chemical corrosives (such as various acids, alkalis, or thick smoke), or severe vibrations.
4.1 Ideal equipment for urban and rural network upgrades: Can be paired with controllers to achieve remote control, remote measurement, remote signaling, and remote adjustment, realizing the "four remote" functions.
4.2 Flexible and Convenient Operation: This product features electric energy storage and electric switching, as well as manual energy storage and manual switching, allowing for operation at close or distant ranges.
4.3 Interruption: The short-circuit current interruption capability is 25kA, achieved 30 times.
4.4 Low operating power, high reliability: The operation of the compact electric spring mechanism (approximately 30W) is reduced to a level.
4.5 Flexible Installation Methods: Column suspension or pedestal mounting options available.
4.6 Sealing: SF6 pressure is at zero gauge pressure and utilizes mature sealing structure technology, ensuring tight sealing and low leakage.
4.7 Wire Entry Method: Utilizes silicone rubber tubes for ample insulation distance between terminal connections and excellent external insulation characteristics.
4.8 Safety in Use: Equipped with explosion-proof devices at the top of the case, high-temperature gases or splashes will not leak out even in the event of internal malfunctions.
