1. Directly connects to Ethernet, across subnets and across routers.
2. Built-in high-definition camera with clear video images and backlit compensation feature.
3. The internal circuit of the telephone utilizes a universal double-sided integrated circuit, featuring accurate dialing, clear conversation, and stable operation.
4. Built-in 10W speaker and AEC algorithm.
5. Surface spray painting on carbon steel, with high mechanical strength and strong impact resistance.
6. All critical components are manufactured in-house, with strict quality control and fast response to after-sales feedback.
7. Can be remotely configured and managed via the web page.
Supply Voltage | DC12VOrPOE |
Standby operating current | ≤1mA |
Communication Protocol | SIP2.0 |
Pixel | 100W |
Ingress Protection (IP) rating | IP65 |
Corrosion Resistance Grade | WF1 |
Ambient Temperature | -30～+60℃ |
Atmospheric Pressure | 80~110KPa |
Relative Humidity | ≤95% |
Lead Wire Hole | 1-Ø10 |
Overall Weight | 2Kg |
Installation Method | Wall-mounted |
Suitable for access control, elevators, and buildings, etc.
Instructions for Use:
1. Press the emergency call button while dialing and the pre-stored number will be dialed automatically → a normal audio and video call will be established once the other party answers.
2. Press the hands-free button to answer calls when picking up the phone, allowing for a normal audio and video conversation between both parties.
3. After the call ends, press the hands-free key to hang up or the call will automatically hang up if there's a busy signal.
