1. The system boasts strong expansion compatibility, supporting standard SIP 2.0 (RFC3261) and related RFC protocols.
2. Features single-button direct dial to dispatch console; 2 functional keys can be set as desired.
3. Full-duplex intercom function; incoming call with audio and visual alerts.
4. Speaker and microphone sensitivity are adjustable; optional voice encoding methods include G.729, G.723, G.711, G.722, and G.726.
5. Telephone Case Design: Waterproof, dustproof, no need for a waterproof cover, both aesthetically pleasing and practical.
6. The internal circuit of the telephone uses a universal double-sided integrated circuit, featuring accurate dialing, clear conversation, and stable operation.
7. Aluminum alloy die-cast shell, high mechanical strength, strong impact resistance.
8. The outer shell surface is high-temperature electrostatic powder coating, with excellent antistatic properties and eye-catching colors.
9. Our company independently produces key components such as handles, hangers, and keyboards, ensuring strict quality control and a quick response to after-sales feedback.

Communication Protocol | SIP2.0(RFC-3261) |
Audio Amplifier | 2.4W |
Hands-free speaker | 2W |
Volume Control | Adjustable |
Support Agreement | RTP |
Encoding and decoding | G.729、G.723、G.711、G.722、G.726 |
Power Supply Method | AC220V OrPoE |
LAN | 10/100base-TX s Auto-MDIX, RJ-45 |
WAN | 10/100base-TX s Auto-MDIX, RJ-45 |
Dimensions | 300*270*130 |
Overall Weight | 5.5Kg |
Installation Method | Wall-mounted |
Applicable to environments with special requirements for moisture-proof, fire-resistant, noise-proof, dust-proof, and frost-proof in subway systems, tunnels, pipelines, highways, power plants, gas stations, docks, and steel mills.



Usage Instructions:
1. Register on the server and make phone calls according to the server's dialing rules.
2. The called party hears the ringtone → lifts the handset to answer the call, and both parties engage in a normal conversation.
3. End the call and hang up the receiver.
