1. The system has strong compatibility for expansion, supporting standard SIP 2.0 (RFC3261) and related RFC protocols.
2. Supports single-button direct dial to the console; the three function keys can be positioned freely.
3. Full-duplex intercom function.
4. Speaker and microphone sensitivity are adjustable; optional voice encoding methods include G.729, G.723, G.711, G.722, G.726, and more.
5. Phone case design with waterproof and dustproof features, no need for a waterproof cover, both aesthetically pleasing and practical.
6. The internal circuit of the telephone uses a universal double-sided integrated circuit, featuring accurate dialing, clear通话, and stable operation.
7. Aluminum alloy die-cast housing, high mechanical strength, strong impact resistance.
8. The outer shell surface is high-temperature electrostatic spray painting, offering good anti-static properties and eye-catching colors.
9. Our company manufactures the handles, hangers, and keyboards for critical components in-house, ensuring strict quality control and a quick response to after-sales feedback.

Communication Protocol | SIP2.0(RFC-3261) |
Audio Amplifier | 2.4W |
Hands-free speaker | 2W |
Volume Control | Adjustable |
Support Agreement | RTP |
Encoding and decoding | G.729、G.723、G.711、G.722、G.726 |
Power supply method | 12V(±15%)/1A DC OrPoE |
LAN | 10/100base-TX s Auto-MDIX, RJ-45 |
WAN | 10/100base-TX s Auto-MDIX, RJ-45 |
Dimensions | 332*200*143MM |
Overall Weight | 3.8Kg |
Installation Method | Wall-mounted |

Applicable to environments with special requirements for moisture-proof, fire-retardant, noise-resistant, dust-proof, and frost-proof, such as subway systems, pipeline tunnels, tunnels, highways, power plants, gas stations, docks, and steel mills.



Instructions for Use:
1. Register on the server and dial phone calls according to the server's dialing rules.
2. The called party hears the ringtone → lifts the handle to answer the phone, and both parties engage in a normal conversation.
3. Hang up the receiver after the call ends.
