1. The system has strong compatibility and supports standard SIP 2.0 (RFC3261) and related RFC protocols.
2. Features single-button direct dial to dispatch console; three function keys can be set as desired.
3. Full-duplex intercom function.
4. Speaker and microphone sensitivity is adjustable; optional voice coding methods include G.729, G.723, G.711, G.722, and G.726.
5. Phone case design with waterproof and dustproof features, no need for a waterproof cover, both aesthetically pleasing and practical.
6. The internal circuit of the telephone uses a universal double-sided integrated circuit, featuring accurate dialing, clear conversation, and stable operation.
7. Aluminum alloy die-cast shell with high mechanical strength and strong impact resistance.
8. The housing surface is high-temperature electrostatic spray painting, with good antistatic properties and eye-catching colors.
9. Our company manufactures the handles, hangers, and keyboards for critical components in-house, ensuring strict quality control and rapid after-sales response.

Communication Protocol | SIP 2.0(RFC-3261) |
Audio Amplifier | 2.4W |
Amplified loudspeaker | 25W |
Volume Control | Adjustable |
Supporting Protocols | RTP |
Encoding and decoding | G.729、G.723、G.711、G.722、G.726 |
Power Supply Method | 12V(±15%)/1A DC OrPoE |
LAN | 10/100base-TX s Auto-MDIX, RJ-45 |
WAN | 10/100base-TX s Auto-MDIX, RJ-45 |
外形尺寸: External Dimensions | 330*241*122MM |
Overall Weight | 6Kg |
Installation Method | Wall-mounted |


Suited for environments with specific requirements for moisture-proofing, fire-retardant, noise-resistant, dust-proof, and frost-proof, such as subway systems, pipeline tunnels, tunnels, highways, power plants, gas stations, docks, and steel mills.



Usage Instructions:
1. Register on the server and make phone calls according to the server's dialing rules.
2. The called party hears the ringtone → picks up the handset to answer the call, and both parties engage in a normal conversation.
3. Hang up the receiver after the call ends.
