Clean Bench

Product Overview: One Cleanroom Workbench

A cleanroom bench is a purification equipment that provides a dust-free working environment, featuring ease of use, simple structure, and high efficiency. It is designed to meet the requirements of cleanliness for local work areas in modern industries, optoelectronics, biomanufacturing, and scientific research experiments.A cleanroom workstation is a local purification device that, within a specific space, indoor air passes through a pre-effect filter, then is forced into a static pressure box by a low-noise fan. It is then filtered through a high-efficiency air filter, and the resulting clean airflow is emitted vertically and evenly, carrying away dust and biological particles to achieve a hundred-level cleanliness in the operational area. This creates a sterile, high-purity working environment.

The Wuxi Cleanroom Bench utilizes an energy-saving top-mounted variable air volume supply system.,High-performance, long-life efficient air filter,Filter efficiency≥99.995%,Powder-coated diffuser panels ensure even air distribution, with vertical laminar flow blowing down and horizontal laminar flow blowing outward, achieving purification. Widely used in industries such as food and health care, sanitation, biotechnology, electronics, cosmetics, cleanrooms, aerospace, and more. Available for custom-made single or double-person vertical and horizontal clean benches, standing operation clean benches, all-stainless steel clean benches, exhaust and dust removal clean benches, and three-person extra-wide clean benches.　

One-Net Workbench Product Advantages:

Advantage One: Branding

Utilizing GermanEBMDirect-drive high-efficiency centrifugal fans for manufacturing, featuring low noise, long lifespan, maintenance-free, and variable speed capabilities. Tested under initial resistance of high-efficiency filters, they are capable of energy-saving.50%Above, effectively reducing the actual operating costs. Service life can last up to50000Over 8 hours.

Advantage Two: Modernized

Brushed finishSUS304Stainless steel worktop, thickness1.22mmCurved corner wrapping, anthropomorphic design, comfortable working environment for staff. Windshield with5MMThick tempered glass design with free positioning and lift. The outer casing is made of cold-rolled steel plates with baked paint, featuring electrostatic spraying. The paint process employs the automotive spray painting technique, with the surface treated through acid pickling, de-greasing, rust removal, painting, and high-temperature baking.

Advantage Three: Flexibility

Can be configured for single-unit use or connected in series for multiple units.100Level flow ultra-clean production line, featuring modular assembly and standalone capabilities with high flexibility. The control method employs an adjustable air volume fan system, touch-type switches, and dual-speed voltage regulation to ensure the working area's air speed is always in an ideal state. The control panel is equipped with an ultraviolet sterilization lamp.,Bulb, fan speed control, soft touch point switch. The entire workbench can be sealed for use.,There are two hand-operated holes on the workbench.,Hand-reach accessibility,And also, the entire panel can be lifted up.,Open for easy operation. Equipped with swivel casters at the bottom for easy positioning and locking, allowing for flexible movement at any time.

Advantage Four: Standardization

All products are manufactured in compliance with U.S. federal standards.209EStrictly inspected on a per-unit basis to meet 100-level cleanroom standards, with on-site dust particle counter testing.0.3And0.5Micron dust particle count is0High reliability.

Principle of operation for cleanroom workbench:

The principle of a clean bench involves filtering indoor air through a pre-filter, then pressurizing it into a static pressure box by a small centrifugal fan. The air is further filtered through a high-efficiency air filter, resulting in a clean airflow with a consistent cross-sectional velocity. This airflow can displace the original air in the work area, carrying away dust and biological particles, to create a sterile, high-purity working environment.

Operation Instructions for Cleanroom Workbench

The advantages of the Wuxi Yijing purification workbench include ease of operation, comfort, and increased work efficiency. Short preparation time, ready to start10Over a minute to operate, it's generally usable at any time. In factory-style production, where a large inoculation workload is involved and extended periods of work are required, a clean bench is an ideal piece of equipment. The clean bench is powered by a three-phase motor for its blow-off power, with a power rating of...145～260WThe air is blown out after passing through a "super filter" composed of stacked layers of specially porous foam plastic, forming a continuous, dust-free and sterile ultra-clean air laminar flow, known as "effective special air," which removes particles larger than0.3μmDust, fungal and bacterial spores, etc. The flow rate of ultra-clean air is24～30m/minThis is sufficient to prevent pollution caused by nearby air disturbances without hindering the sterilization of equipment with alcohol or Bunsen burners. The staff operates under these sterile conditions, ensuring that sterile materials remain uncontaminated during transfer and inoculation. However, in the event of a power outage during the procedure, materials exposed to unfiltered air are at risk of contamination. In such cases, work should be terminated immediately, and a mark should be made on the bottle. If the contents are in the proliferation stage, they should no longer be used for proliferation and should be transferred to root culture instead. For general production materials that are abundant, they may be discarded. If they are in the root formation stage, they can be saved for future planting.

Cleanroom Bench Maintenance:

1Based on actual usage, remove and clean the preliminary filter regularly; the cleaning cycle is generally...3~6Month. (If not washed regularly, accumulated dust can affect insufficient airflow and reduce the cleaning efficiency.)

2If the ideal cross-sectional air velocity is not achieved after a normal replacement or cleaning of the initial efficiency air filter, adjust the working voltage of the fan (turn the knob) to reach the desired uniform air velocity (when starting a new workbench, adjust the fan's working voltage to)80V~90VAvailable).

3After 18 months of use, if the fan's working voltage is adjusted to the highest point and the desired wind speed is still not achieved, it indicates that the high-efficiency air filter has accumulated too much dust (the filter holes on the filter material are mostly blocked, and it is necessary to replace it promptly). The lifespan of a high-efficiency air filter is generally 18 months.

4When replacing a high-efficiency air filter, ensure the correct model, specifications, and dimensions (as originally configured by the original manufacturer), install it according to the arrow indicating wind direction, and be mindful of the surrounding seal to prevent any leakage.

A variety of purification products in various specificationsAvailable in stock, ready for immediate selection by customers.

General Specifications of Standard Clean Bench Tables

Wuxi One Clean Super Clean Bench Patent Certificate
