Clean Bench

Product Overview: One Cleanroom净化 Workbench

A Cleanroom Bench is a purification equipment that provides a dust-free working environment, featuring ease of use, simple structure, and high efficiency. It is designed to meet the requirements of cleanliness in local work areas for modern industries, optoelectronics, biomanufacturing, and scientific research experiments.A cleanroom bench is a local purification unit that, within a specific space, indoor air passes through a pre-filter and is then forced into a static pressure box by a low-noise fan. It is further filtered by a high-efficiency air filter, and the resulting clean airflow is emitted uniformly at a vertical angle, removing dust and biological particles. This achieves a hundred-class clean environment in the operational area, creating a sterile and highly clean working atmosphere.

The Wuxi Cleanroom Clean Bench utilizes an energy-saving top-mounted variable air volume supply system.,Equipped with high-performance, long-life efficient air filters,Filter efficiency is≥99.995%,The electrostatically coated diffuser panels ensure even air distribution, with vertical laminar flow blowing down and horizontal laminar flow blowing outward, achieving purification. Widely used in industries such as food and health care, sanitation, biotechnology, electronics, cosmetics, clean rooms, aerospace, and more. Customizable options include single or double-person vertical ultra-clean benches, single or double-person horizontal ultra-clean benches, standing operation ultra-clean benches, all stainless steel ultra-clean benches, exhaust and dust removal ultra-clean benches, and three-person extra-wide ultra-clean benches.　

Advantages of a Single-Desk Workstation:

Advantage One: Branding

Utilizing GermanEBMDirect-drive high-efficiency centrifugal fans for manufacturing, featuring low noise, long lifespan, maintenance-free, and variable speed capabilities. Tested to be energy-saving under initial resistance conditions in high-efficiency filter systems.50%Above, effectively reducing the actual operating costs. Service life can last50000Over 8 hours.

Advantage Two: Modernized

Brushed finishSUS304Stainless steel worktop, thickness1.22mmCurved corner edge binding, ergonomically designed for comfort in the worker's operational environment. The windshield is made of5MMThick tempered glass design with free positioning and lifting. The outer casing is made of cold-rolled steel plate with baked paint finish, featuring electrostatic powder coating. The baked paint process employs automotive paint finishing techniques, with the surface being treated through acid washing, phosphatizing, degreasing, rust removal, spraying, and high-temperature baking.

Advantage Three: Flexibility

Can be configured for single-unit operation or linked in series for multiple units.100Grade A ultra-clean production line, featuring modular assembly and standalone usage with high flexibility. The control method employs an adjustable air volume fan system, touch-type switches, and dual-speed voltage regulation to ensure the working area's wind speed is always in an ideal state. The control panel is equipped with an ultraviolet sterilization lamp.,Bulb, fan speed control with soft touch switch. The entire workbench can be used in a sealed manner.,There are two hand-operated holes on the workbench.,Hand-reachable,And the entire panel can also be lifted up.,Open for easy operation. Equipped with swivel casters at the bottom for easy positioning and locking, providing flexible movement.

Advantage Four: Standardization

All products are manufactured in compliance with U.S. federal standards.209EEach unit undergoes rigorous inspection in compliance with a 100-level purification standard, with on-site dust particle counter measurements.0.3And0.5Micron dust particle count0High reliability.

Principle of Operation for Clean Bench:

The principle of the clean bench is that indoor air is initially filtered through a pre-filter, then forced into a static pressure box by a small centrifugal fan. It is further filtered through a high-efficiency air filter in two stages. The clean airflow blowing out from the high-efficiency air filter has a certain and uniform cross-sectional velocity, which can displace the original air in the work area and carry away dust and biological particles, thereby creating a sterile and high-purity working environment.

Operation Instructions for Cleanroom Workbench

The advantages of the Wuxi One Clean purification workbench include easy and comfortable operation, and improved work efficiency. Short preparation time, ready to start10Minutes above can be operated, basically usable at any time. In factory production, the inoculation workload is substantial, and when it is necessary to work for long periods, a clean bench is an ideal piece of equipment. The clean bench is powered by a three-phase motor for its blowing power, with a power rating145～260WAir is blown out after passing through a "super filter" made by layering sheets of special micro-porous foam, forming a continuous, dust-free and sterile ultra-clean air laminar flow, known as "effective special air." It removes particles larger than0.3μmDust, fungal and bacterial spores, etc. The airflow rate of the ultra-clean air is24～30m/minThis flow rate is sufficient to prevent potential air disturbances from nearby from causing contamination, and it will not interfere with the sterilization of equipment by burning with alcohol or Bunsen burners. The staff operates under these sterile conditions, ensuring that the sterile materials remain uncontaminated during transfer and inoculation. However, in the event of a power outage during the procedure, the materials exposed to unfiltered air are prone to contamination. In such cases, work should be quickly terminated and a mark made on the bottle. If the contents are in the proliferation stage, they should no longer be used for proliferation and instead be transferred to rooting culture. For general production materials that are abundant, they may be discarded. If they are in the rooting stage, they can be reserved for later planting.

Maintaining Clean Workbenches:

1According to actual usage, remove and clean the pre-filter regularly; the cleaning cycle is generally...3~6Months. (If not cleaned regularly, accumulated dust can reduce air intake and lower the cleaning effectiveness.)

2After normal replacement or cleaning of the primary air filter, if the desired cross-sectional air velocity is still not achieved, adjust the working voltage of the fan (by turning the knob) to reach the ideal uniform air velocity (when the new workbench is initially used, adjust the working voltage of the fan to)80V~90VAvailable).

3After 18 months of use, if the fan's working voltage is adjusted to the highest point and the ideal wind speed is still not achieved, it indicates that the high-efficiency air filter has accumulated too much dust (the filter holes on the filter material are mostly blocked, and it is necessary to replace it promptly). The general lifespan of a high-efficiency air filter is 18 months.

4When replacing high-efficiency air filters, pay attention to the correct model, specification, and size (as originally configured by the original manufacturer), install according to the arrow indicating wind direction, and ensure there are no leakage around the filter.

Various specifications of purification productsAvailable in stock, ready for immediate selection by customers.

Standard Clean Bench Technical Parameters Overview

Wuxi First Clean Ultra-Clean Bench Patent Certificate
