A structure
Composed of a gas-liquid mixing chamber, gas-liquid distributor, absorption weir, absorption matrix heat exchange blocks, gas-liquid separator, metallic外壳, etc. The blocks are sealed between each other with fluoroelastomer or flexible graphite "O" type sealing rings, or acid-resistant flat rubber rings.
Excellent absorption (high and low finished product acidity), good vibration resistance, strong impact resistance, long service life, stable operation and easy maintenance, and strong applicability.
Scope of B
Absorbing equipment for synthetic hydrogen chloride gas, chlorinated oil off-gas or other off-gases containing hydrogen chloride, hydrogen fluoride gas, sulfur dioxide, ammonia gas, etc.
C Specification and Installation Dimensions
D Model Graphite Absorber Technical Parameters
Allowable Stress: Longitudinal ≤ 0.1 MPa, Lateral ≤ 0.4 MPa
Finished Product Acid Concentration <= 35%
Inlet Temperature <= 170°F
Cooling water consumption <= 2 T/h per square meter.
Finished acid output <= 5T/h per square meter.
