Japanese Magnescale Reading Head PL20C-30

价      格Negotiable

最小起订0 Piece库存0 Piece

Location
Jiangsu Suzhou
有效期至
长期有效
最后更新
2025-01-08 14:59
View Count
30
咨询Floor Price 查看You can contact your customer with the following information

Business Card

  • Your company's名称Suzhou Quantum Instrument Co., Ltd.
  • 联 系 人李成国 （先生）
  • Your company'sPhone13862144080
  • Mobile号码13862144080
  • Company Address199 Ta Yun Road, Yuxi Town, Wuzhong District, Suzhou, Jiangsu Province
收藏商品 分享 扫一扫用手机扫描二维码直达商品手机版

买家正在看

  • Mitutoyo 293-668-20 Micrometer Ruler

    Negotiable

  • Wan Hao VMS-5040H Automatic Image Cytometer, Visual Measurement Instrument

    Negotiable

  • Mitutoyo Sumitomo Short Arm Inside Diameter Gauge 511-762

    Negotiable

  • Mitutoyo Sinebar 500-722-20 Coolant-Resistant Caliper

    Negotiable

猜你喜欢
Mitutoyo Sankyo Three-Jaw Hole Mi Mitutoyo Sankyo Three-Jaw Hole Mi Negotiable Mitutoyo Sensitive Short Arm Insi Mitutoyo Sensitive Short Arm Insi Negotiable Japanese Magnescale Magnetic Scal Japanese Magnescale Magnetic Scal Negotiable Mitutoyo Mitutoyo Micrometer Head Mitutoyo Mitutoyo Micrometer Head Negotiable Japan Magnescale Caliper Sensor D Japan Magnescale Caliper Sensor D Negotiable Mitutoyo Sanwa Coolant-Resistant Mitutoyo Sanwa Coolant-Resistant Negotiable Mitutoyo Sartorius Dial Indicator Mitutoyo Sartorius Dial Indicator Negotiable Japan Magnescale Magnetic Scale S Japan Magnescale Magnetic Scale S Negotiable Rational Wanhowa Horizontal Proje Rational Wanhowa Horizontal Proje Negotiable Mitutoyo Sinebar 511-805 with Mic Mitutoyo Sinebar 511-805 with Mic Negotiable
Product Details
Output Signal：
Array
Resolution：
10 μm
Responsive speed：
300 m/min

Japan Magnescale Reading Head PL20C-30

Cable for installing magnetic encoder scale heads

  • Resolution: 10 µm

  • Response Speed: 300 m/min

  • Output Signal: A/B Phase (Pulse) (Compliant with EIA-422)

Key Specifications

Changes to the content will be made without prior notice.

ModelPL20C
PL20C-3 / -3CPL20C-5 / -5CPL20C-10 / -10CPL20C-15 / -15CPL20C-20 / -20CPL20C-30
Sensor cable length3m5m10m15m20m30m
Output SignalA/B Differential (Pulse) (Compliant with EIA-422)
Resolution10μm
Responsive speed300m/min
Screw Torque for Sensors0.7 ～ 1.1 N・m
Operating Temperature Range0 ～ +45℃
Storage Temperature Range-10 ～ +50℃
