Mitsubishi Peak Hold Digital Indicator 543-300-10

Mitutoyo Three丰 Peak Hold Digital Indicator 543-300-10

543 Series

Peak-Holding Digital Indicator ID-C112AX2

Peak detection function available, with the capability to make GO/±NG judgments for peaks. *1

● Equipped with 5 buttons, status icons, and key assist displays, various functions are easy to operate.

● Equipped with a large LCD screen and analog bar display.

● Utilizes SainSmart developed ABS (ABSOLUTE) encoder, no need to reset to zero upon power off and on, *2, thus avoiding overspeed errors and enhancing measurement reliability.

● By utilizing the parameter setting suite (options) and software, various functions and parameters can be set on the PC.

● Equipped with a data output port for measurement, it can be connected to Statistical Process Control systems and measurement data network systems.

■ Features

Peak Detection Function (High/Low)

● Amplitude Detection Function (difference between high and low values during motion) Note: Peak Detection Capability

Sample Rate: 50 times per second

② Capture Speed: 50 µm/sec

Zeroing Function (INC Measurement System Origin Setting)

● Preset Function (ABS Measurement System Origin Setting)

Count Direction Conversion Function

● Tolerance Judgment Function (ABS for three sets, INC can be stored)

Resolution Switching Function

● Simple Calculation Function f(x) = Ax

● Simulated Gauge Graduation Value Switching Function

●Function Lock Feature

● Retain Display Value Feature (when no external devices are connected)

Data Output Function

External PC Setting Input Function

● Display Section Rotation Function (330°)

Low Voltage Warning Display

● Error Warning Display
