Mitsubishi Electric Calculating Digital Indicator 543-590B-10

Mitsubishi 543-590B-10 Calculating Digital Indicator

543 Series

Absolute Digital Indicator ID-C112RXB2

● Built-in rod displacement calculation function. By setting installation calculation coefficients on various fixtures, measurement results can be directly read.

Fruit, an indicator with strong scalability.

● By connecting to a computer and using the parameter setting kit (optional) and software, various settings can be made.

●With 5 buttons, status icons, and key-assisted displays, a simple operation with rich functions is achieved.

■ Features

● Calculation Function f(x)' ) = Ax'+ B + Cx' -1 ( x= x plus offset

Peak Detection Function (High/Low)

●Function for detecting amplitude of fluctuation (difference between high and low values during motion)

Note: Peak detection capability

Sample Rate: 10 times per second

② Capture Speed: 10 µm/sec

By setting

Sample Rate: 50 times per second

② Capture Speed: 50 µm/sec

Can toggle

Zeroing Function (INC Measurement System Origin Setting)

● Pre-set Function (ABS Measurement System Origin Setting)

● Tolerance Judgment Function (ABS three sets, INC can be stored)

● Simulation Bar Division Value Switch

● Function Lock Feature

● Display Value Hold Function (No External Device Connected)

Data Output Feature

● External PC Setup Input Function

● Display Section Rotation (330°)

Low Voltage Warning Display

● Error Warning Display

● Resolution Switch Function

■ Options ▶ See details on pages 07-11.

● Lift Rod Option

Measuring Rod Lift Rod: No. 21EZA198

Lever for Measuring Rod: No. 21EZA105
