RLA220 Collapsible Precision Electric Cylinder

Collapsible precision electric cylinders are suitable for installations with limited space due to their short overall length. Additionally, the imported synchronous belts used in this solution feature high strength, small gaps, and long service life, which contribute to the cylinder's high controlability and precision. The servo motor pairs well with the electric cylinder, offering easy installation, simple setup, and convenient use.

Product Details Introduction

Section 1: Servo Electric Cylinder Working Principle
An electric cylinder is a modular product with an integrated design that converts the rotational motion of a servo motor into linear motion through the mechanical movement of a screw and screw nut pair. By utilizing the closed-loop control characteristics of the servo motor, precise control over thrust, speed, and position can be easily achieved; combined with mechanical motion technology and programmed control technology, it realizes programmed and numerical control. It is a revolutionary new product that achieves high-precision linear motion control.

Section II: Electric Cylinder Types
Direct-Acting Electric Cylinder
Direct-actuated electric cylinders integrate AC servo motors, servo drives, high-precision ball screws, and modular design technologies, offering features such as compact structure, low inertia, fast response, low noise, and long lifespan. The servo motor is directly connected to the transmission screw of the cylinder, reducing the inertia and clearance of intermediate links, enhancing control and precision. The servo motor is integrated with the cylinder for easy installation and convenient use. The main components of the cylinder are all made with internationally renowned brands, ensuring stable performance, low failure rate, and high reliability.
2. Folding Electric Cylinder
Folding electric cylinders are suitable for installations with limited space due to their short overall length. Additionally, the imported synchronous belts used in this solution offer high strength, small gaps, and long lifespan, enhancing the entire cylinder's control and precision. The servo motor pairs well with the cylinder, making installation easy, setup simple, and usage convenient.

Section 3: Electric Cylinder Models

IV. Overview of Electric Cylinder Features

1. Precise path positioning and controllability
2. Modular assembly applications, saving mechanical design space
3. Suitable for high-speed, high-frequency operation
4. Precise and easy to install
5. Multi-point positioning and multi-segment control
6. Various installation accessories and methods available for selection
7. Available with a variety of complete motor and controller sets.
8. A wide variety of products are available for selection.
9. Simple design, low maintenance costs, and easy to handle.

V. Electric Cylinder Usage Instructions and Precautions
1. Electric cylinders are precision electromechanical integrated transmission equipment. Please carefully read the precautions and the manuals for the motor, driver, and other components before use.
2. This product features an internal high-strength magnet, equipped with a magnetic induction switch and a stroke limit warning sign externally. Please fine-tune the required stroke within the warning sign.
3. Our company uses a full-sealed device, filled with high-quality lubricating oil, which requires no regular maintenance from customers; for certain high-frequency and high-speed models, we have designed a personalized lubricating oil filling port.
4. During the servo electric cylinder debugging, start with low-speed point operation, and only increase the speed after all aspects are functioning normally to prevent damage to the electric cylinder.

Section 6: Application Scope
Multi-degree-of-freedom simulation and simulation, multi-degree-of-freedom motion entertainment, precision machining, robots, mechanical lifting platforms, automotive presses, automotive manufacturing equipment, automated machinery production lines, petrochemical industry, material handling, injection molding machines, mold control, valve control, precision machine tools, food industry, and more.

Section 7: After-Sales Instructions and Recommendations
1. This product comes with a one-year warranty from the date of factory shipment, under normal usage conditions (excluding any damage caused by misuse).
2. Damage caused by human factors or other abnormal use is not covered under the warranty.
3. Unauthorized disassembly of the electric cylinder without the manufacturer's permission is not covered under warranty, including any self-disassembly or modification.
