RLA94 Return Type Electric Cylinder

Retractable electric cylinders are suitable for installations with limited space due to their short overall length. Additionally, the imported synchronous belts used in this solution offer high strength, minimal gaps, and long lifespan, resulting in excellent control and precision for the entire cylinder. The servo motor works seamlessly with the cylinder, featuring easy installation, simple setup, and convenient operation.

Product Details Description

One, Working Principle of Servo Electric Cylinder
An electric cylinder is a modular product with an integrated design that converts the rotational motion of a servo motor into linear motion through the mechanical movement of a screw and screw nut pair. Leveraging the closed-loop control characteristics of the servo motor, precise control over thrust, speed, and position can be easily achieved; combined with mechanical motion technology and programmed control technology, it achieves programmed and numerical control. It represents a revolutionary new product for achieving high-precision linear motion control.

Section II: Electric Cylinder Types
Direct-Connected Electric Cylinder
Direct-acting electric cylinders integrate AC servo motors, servo drives, high-precision ball screws, and modular design technologies, offering compact structure, low inertia, fast response, low noise, and long lifespan. The servo motor is directly connected to the cylinder's transmission screw, reducing the inertia and clearance of intermediate links, enhancing control and precision. The servo motor and cylinder are integrated for easy installation and convenient use. The main components of the electric cylinder are all made with internationally renowned brands, ensuring stable performance, low failure rate, and high reliability.
2. Folding Servo Electric Cylinder
Folding electric cylinders are suitable for smaller installation spaces due to their short overall length. This design utilizes imported synchronous belts, which offer high strength, minimal gaps, and a long service life, enhancing the cylinder's control and precision. The servo motor pairs with the cylinder seamlessly, featuring easy installation, simple setup, and convenient operation.

Section 3: Electric Cylinder Models

4. Overview of Electric Servo Cylinder Features

1. Precise path location and controllability
2. Modular assembly applications, saving mechanical design space
3. Suited for high-speed, high-frequency operation
4. Precise and easy to install
5. Multi-point positioning and multi-segment control
6. Attachments and installation methods are available in a variety of options.
7. Available with a variety of full sets of motors and controllers.
8. Product variety available for selection.
9. Simple design, low maintenance costs, and easy to handle.

V. Electric Cylinder Usage Instructions and Precautions
1. Electric cylinders are precision electromechanical integrated transmission equipment. Please carefully read the precautions and the instruction manuals for the motor, driver, and other components before use.
2. This product features an internal high-strength magnet, equipped with a magnetic induction switch and a stroke limit warning sign externally. Please fine-tune the required stroke within the warning sign area.
3. Our company utilizes a full-sealed unit, filled with high-quality lubricant, eliminating the need for regular maintenance from customers; for specific high-frequency and high-speed applications, we have customized designs with lubricant injection ports.
4. When adjusting servo electric cylinders, start with slow, intermittent movements. Only increase speed once everything is functioning normally to prevent damage to the cylinder.

Section 6: Application Scope
Multi-degree-of-freedom simulation, multi-degree-of-freedom motion entertainment, precision machining, robots, mechanical lifting platforms, car presses, automotive manufacturing equipment, automated production lines, petrochemicals, material handling, injection molding machines, mold control, valve control, precision machine tools, food industry, and more.

Section 7: After-Sales Instructions and Recommendations
1. This product comes with a one-year warranty from the date of factory shipment, under normal usage conditions (excluding人为 damage).
2. Damage caused by human factors or abnormal use is not covered under warranty.
3. Unauthorized disassembly of the electric cylinder is prohibited without the manufacturer's permission; any self-disassembly or modification is not covered under warranty.
