Communication Pressure Tester

Product Overview

EDThe NY-H Portable Voltage Resistance Tester is developed and manufactured by Hubei Electric Power. It is suitable for testing the safety voltage and leakage current of various motors, electrical appliances, instruments, meters, and home appliances, as well as for strong electrical systems. The instrument is easy to operate, safe and reliable, with good performance and convenient maintenance. It meetsGB 4706.1 "General Requirements for Safety of Household and Similar Electrical Appliances" and GB 9706.1Please provide the Chinese content to be translated. Please provide the Chinese content that needs to be translated into American English.General Requirements for Electrical SafetyTesting equipment required for the trial requirements of related clauses in national standards such as GB4943 and GB4793

Product Alias

Voltage Testers, AC Voltage Testers, Portable Voltage Testers

Product Features

1. Digital display

2. Display the leakage current value on the item being tested during the test

3. Time preset and display, countdown timer for testing

4. Adjustable alarm current value setting

Output waveforms are 50Hz sine waves.

Technical Specifications(Special parameters available for customization)

VolumekVA） 1

Output VoltagekV） Range 0～5

Basic Error ±5%

Leakage CurrentmA） Range 0～200

Basic Error ±（5%r+3d）

Alarm CurrentmA） 0.5～200

Test Time 1～99s

Dimensions 320×325×205mm3

Weight 12.5kg

Ambient Temperature 0～40℃

Relative Humidity ≤80%

Power Supply 220V±10%，50Hz
