Extensive high-voltage tests are required in power systems, testing institutions, research institutes, and other units. Due to the high test voltage, violations can pose a severe threat to personal and equipment safety, with potentially catastrophic consequences. Although there are strict operational procedures for high-voltage testing, tragedies still occur in practice due to insufficient experience of test personnel, negligence, and inadequate supervision.

High-voltage Transformers, Switchgear, Large TransformersGISHigh-voltage equipment such as busbars and withstand voltage tests pose risks due to large pressurized areas with blind spots, despite temporary barriers and personnel guarding. Non-high-voltage test personnel may still inadvertently enter the pressurized zone. If staff have a lack of safety awareness, violate regulations, or fail to supervise properly, someone might cross the barriers, posing a severe threat to their safety, especially during large-scale power maintenance operations. In accordance with the "Power Safety Work Regulations of the State Grid Corporation of China," safety protection measures must be implemented during high-voltage tests. Therefore, it is urgently necessary to develop a system that can provide comprehensive protection for the personal safety of test personnel, which is of significant practical importance. Moreover, it will enhance the efficiency of high-voltage testing and strengthen staff safety awareness.

Product Overview

The system design incorporates basic electronic technology.,Through design steps such as infrared detection, signal collection, signal processing, logical processing, relay protection, control output, triggering alarms, and automatic disconnection, the various unsafe factors are fully considered, endowing it with high safety protection capabilities.
