Product Performance
Date:固有 opening and closing times for 12 circuit breakers, same phase and phase-to-phase synchronization.
Reclosing: Closing and opening at each break (gold short time), opening and closing without current interval time, opening-closing-opening.
Bounce: Closing bounce time per circuit, bounce count, bounce process, and bounce waveform.
Speed: Separation and rejoining speed, high speed, time-distance characteristic curve.
Trip: Total distance, starting distance, overtravel distance, overshoot distance, rebound amplitude.
Electrical Current: Split and close circuit current values, current waveform diagram.
Action Voltage: The internal DC 30～250V/20A (instantaneous operation) digital adjustable circuit breaker action power supply automatically completes the low-voltage action test of the circuit breaker and measures the action voltage value of the circuit breaker.
Product Features
SF6 switches, GIS integrated electrical equipment, vacuum switches, and oil switches suitable for all models of metal contacts in domestic and international production.
Universal speed sensors, linear travel sensors, and rotary sensors, all featuring extremely easy and straightforward installation.
Monitor with large screen, transparent, and backlit LCD, with electronic contrast adjustment. Full Chinese menu prompts for operation; a single switch action displays all data and waveform diagrams.
The machine can store multiple groups of field switch-on and switch-off test results, with an internal real-time clock for easy archiving and saving the test date and time.
Built-in rapid mini printer, printing all data and graphs.
The instrument is equipped with the "Circuit Breaker Data Analysis Management Software" for PC connection, allowing test results to be directly saved to the hard drive or printed out on various printers as test reports.
The instrument boasts powerful data analysis capabilities, enabling effective analysis of various indicator parameters related to the mechanical characteristics of circuit breakers.
The instrument is equipped with a customizable speed addition program, allowing users to freely add various opening and closing speed definitions as needed.
Optional high-precision distance and speed laser sensor available.
