High-Voltage Switch Mechanical Characteristic Tester

Product Performance

Date:固有 opening and closing times of 12 circuit breakers, same phase and inter-phase synchronicity.

Reclosing: Closing and opening at each breaker (gold short time), opening and closing (no current interval), opening-closing-opening.

Bounce: Closing bounce time per circuit, bounce count, bounce process, and bounce waveform.

Speed: Split and close speed, high speed, time-travel characteristic curve.

Trip: Total mileage, opening distance, overtravel distance, overshoot distance, bounce amplitude.

Electric Current: Break and close current values of the switch coils, current waveform diagrams.

Action Voltage: The internal DC 30～250V/20A (instantaneous operation) adjustable circuit breaker, which automatically completes the low-voltage operation test of the circuit breaker, measuring the action voltage value of the circuit breaker.

Product Features

SF6 switches, GIS integrated switchgear, vacuum switches, and oil switches suitable for all models of metal contacts for domestic and international production.

Universal speed sensors, linear travel sensors, and rotary sensors, featuring extremely easy and straightforward installation.

High-definition main screen, transparent, backlit LCD, contrast electronically adjustable. Full Chinese menu prompts for operation; one switch action displays all data and waveform charts.

The main unit can store multiple sets of on-site opening and closing switch test results, an internal real-time clock for easy archiving and saving test dates and times.

Built-in rapid mini printer, printing all data and graphs.

The instrument is equipped with the "Circuit Breaker Data Analysis Management Software" for PC connection, allowing test results to be directly saved to the hard drive or printed on various printers for test reports.

The instrument boasts powerful data analysis capabilities, enabling effective analysis of various indicators and parameters related to the mechanical characteristics of circuit breakers.

The instrument is equipped with a custom speed addition program, allowing users to freely add various opening and closing speed definitions as needed.

Optional high-precision distance and speed laser sensor available.
