High-Precision Temperature Tester

Product Features

Xin Hua FuThe company's productionPD-1020The Dry Body Temperature Calibrator, designed with precision for its compact and portable size; featuring simple and convenient operation; ideal for field and worksite use.No content provided.Locations powered by AC supply12VDirect current (DC) power supply solutions are particularly suitable for maintenance, inspection, and on-site calibration of various temperature sensors, direct-reading spot temperature gauges, and various types of temperature switches, as well as for comparative calibration of short probe temperature probes.

UtilizePD—1020Dry Body TemperatureCalibrateThe device can locally simulate an actual temperature source, providing a real and accurate verification solution for the temperature measurement system you discover or suspect. It can eliminate the hassle of disassembling components for laboratory calibration and the potential for errors, especially for systems that require regular calibration and inspection.

When you useXinhua FuThe company isDuring the calibration of the temperature controller for the Liezhen body, its compact size, unrestricted by power supply, and rapid heating and cooling characteristics will make you feel...Convenient, quick, accurate, and reliable.Due to the adoption of semiconductor heating(Cooling)The advanced design concept for temperature control ensures an almost idealized experience during use. Key features include:

Employing semiconductor heating and cooling technology

You can set it as low as you need below the ambient temperature.45℃Highest110℃Our product operates within a wide temperature range without the use of Freon refrigerants. It meets the design specifications for portable instruments with its precise temperature control, stability, rapid heating and cooling, energy efficiency, and environmental friendliness.

Compact and portable in size

Only268×125×256mmVolume includes temperature control system for the hot tank, cooling and power supply system, convenient for field and on-site use.

Multiple power supply options

No Chinese content provided.220VAC/50HZNo content provided for translation.12VDCDirect current (DC) powered, with an internal battery charging circuit, capable of12V/7AhLead-acid maintenance-free battery charging. Equipped with multiple manual misconnection protection features.

Rapid temperature change

From ambient temperature25℃Reached110℃Approximate time required8Minute; and from110℃Reduced0℃Approximately required time18Minutes; this performance is particularly suitable for temperature switch inspections and calibration.

Optional4Hollow composite casing and large-diameter fluid-filled casing

■4Hollow composite tubes possess excellent thermal conductivity properties.1/8”、1/4”No content provided for translation.3mm、6mmDeep holes facilitate the comparison and verification of multiple thermometers. Large-diameter filling sleeves can be used for non-standard temperature probes, significantly improving thermal conductivity characteristics.

No Chinese content provided for translation..No Chinese content provided.The company's latest news: The company's latest news:PIDThermocouple Controller

■ PD-1020Dry-Type Temperature Calibrator equipped withPlease provide the Chinese content to be translated..Certainly.All-DigitalPIDTemperature Controller, enabling the tank temperature fluctuation to be controlled within ±0.02℃。

Excellent temperature field uniformity

■  Please provide the Chinese content that needs to be translated into American English.0The temperature field uniformity between two horizontal points is approximately ±℃.0.03℃。

Achievable temperature control at varying speeds

When users need to adjust the rate of temperature increase or decrease.PIDThe thermostat can adjust the rate of temperature change according to your specifications, which is very useful for the calibration of industrial temperature switches.

Environmental Protection and Energy Efficiency

Fluorine-free refrigerants in compliance with global environmental agreements.

Technical Performance Specifications

Temperature Range:Below ambient temperature45℃Highest110℃

Work Medium: Air

Vessel Size: Diameter20mmDeep150mm

Work Area: Diameter16mmNo Chinese content provided for translation.138mm

Cooling/Heating Method: Semiconductor Electrothermal Refrigeration Pile

Temperature Control Method: Fully DigitalPIDTemperature Control

Display Resolution:0.01℃

Temperature control stability: superior±0.02℃

Display Accuracy:±0.2℃ (Calibrated)

Heating Time: Approximately8Minute20℃ Rises110℃）

Cooling-off Period: Approximately18Minute110℃ Drop to0℃）

Working Voltage:220V±10%Single-phase AC Mains Power12V/7AH(Anticlock) DC battery powered.

Rated Power Consumption:90 W

Body Dimensions:268×125×256mm

Clean    Re: Approximately7.5Pounds
