Engine Test Bench

The motor testing bench is used to measure the voltage, current, input power, output torque, speed, output power, efficiency, temperature, vibration, and noise of motors. It can conduct type tests, factory tests, and performance tests, serving to evaluate the comprehensive performance of motors and providing accurate data for motor research and development, production, and repair. It is widely applied in the fields of new energy vehicles, ships, coal mines, and university teaching.

Power Measurement Range: 1KW-3000KW

Measurement Speed Range: 0-25,000 r/min

Motor Types: Three-phase asynchronous motors, permanent magnet synchronous motors, high-power DC motors, etc.

Equipment Composition:

Tachometer-torque sensors (or tachometer, load sensors), current sensors, voltage sensors, temperature sensors, vibration/noise sensors, controllable analog loaders (such as dynamometers, eddy current simulators, water eddy current simulators, etc.), cast iron mounting platforms, fixtures, couplings, electrical control cabinets, computer data acquisition real-time control systems, intelligent electrical parameter meters (or power analyzers), motor testing software, MAP efficiency cloud charts.

Standard test items for the motor testing bench are as follows:

1. Empty Load Test

2. Load Test

3. Temperature Rise Test

4. Efficiency Test

Optional test projects for the motor testing bench are as follows:

1. Block Rotation Test

2. Over-speed Test

3. Reverse Voltage Test

4. Direct Current Resistance Measurement

5. Insulation Resistance Measurement

6. Power Frequency Insulation Resistance Test

7. Insulation Resistance Test
