Overview：

1The Generator Armature Sheet Resistance Tester is a specialized device for detecting the resistance of generator armature sheets.,By detecting the resistance between the armature strips of a generator motor, one can effectively verify the quality of the welding between the commutator segments and the winding, and identify any不良phenomena such as open circuits or short circuits in the winding.

2Our instrument utilizes a high-precision constant current power supply, essential for the production and maintenance of DC motors.First.SelectedEquipment. The testing of inter-lamination resistance in DC motor windings is an effective means to detect the balance of stator winding resistance. The preventive testing regulations for electrical equipment have specific provisions for this test. The inter-lamination resistance tester consists of a constant current power supply, a voltage detection circuit, and a control circuit, allowing adjustable output current, stable current, and direct display of resistance values. Data can be read directly, significantly enhancing measurement speed. It is an upgraded product that replaces the previous models that required manual calculations after displaying voltage and current readings on a meter.

This tester utilizes a micro single-chip microcontroller for control and features a user-friendly Chinese character interface display. Its testing current employs5mA-10AOptionalThe instrument utilizes liquid crystal displays to test current and resistance values, which can be printed out. It offers precise measurements, stable performance, and easy operation.

2 Safety Matters

★ This instrument is suitable for both indoor and outdoor use; however, it should be avoided in areas prone to rain, corrosive gases, dust, and high temperatures.

★ Please read this manual thoroughly before using the instrument.

★ Operators of the instrument should possess general knowledge of the use of electrical equipment or instruments.

★ This gauge is a high-precision instrument and should be avoided from剧烈 vibrations.

★ Maintenance, repair, and adjustment of this instrument should be performed by professionals.

★ Always wait for the discharge indicator to complete before turning off the power and removing the test wires.

★ Ensure to wait until the discharge prompt ends before switching the transformer's tap position.

★ During testing, the disassembly and movement of the test fixtures and power lines are prohibited.
