Current and Voltage Transformer Load Box

EDSeriesCurrent Transformer Load Box, Voltage Transformer Load BoxPTLoad BoxCTLoad box,Current and voltage transformer load boxes, as well as transformer load boxes, are used for testing current and voltage transformers.PT/CTThe Transformer Load Box offers a variety of effective loads, making it an ideal matching product for various transformer calibration devices. The Transformer Load Box is designed in accordance with standards.JJG313-94"Current Transformer Calibration Regulation Production and R&D"

EDSeriesTransformer Load Boxes Include Current Transformer Load Boxes and Voltage Transformer Load Boxes(Load)Load Boxes, the transformer load boxes provide an effective load for testing current and voltage transformers. Transformer load boxes are an ideal companion product for various transformer calibration devices, and they are manufactured according to standards.JJG313-94"规程 for Current Transformers Calibration"JJG314-94The newly developed current transformer is designed according to the "Current Transformer Calibration Regulation." It boasts advantages such as a large output capacity, a comprehensive range of load types, lightweight, attractive appearance, and strong stability. The transformer loading box, with its large output capacity and strong stability, is an essential product for the current transformer calibration setup.

Load Box Alias

Transformer Load Boxes, Voltage Transformer Load Boxes, Transformer Load Cells(Current, voltage)Load Box, Current Load Box, Voltage Load Box, Transformer Load Box, Current Transformer Load Box, Voltage Transformer Load Box, Transformer Load Box(Electric Current, Voltage)Load Boxes, Current Load Boxes, Voltage Load Boxes, Transformer Load Boxes, Current Transformer Load Boxes

Load Box Function

1Lightweight and aesthetically pleasing.

2The transformer load box has a large capacity.

3The transformer loading box boasts strong stability.

Load Box, Load Housing Specifications

EDSeriesTransformer Load Box Parameters: Please refer to the product manual or contract for accuracy. If you find any technical parameter information to be incorrect, we welcome corrections.

Transformer Load Tank Model EDSeries

Transformer Load Tank Transformer Load Box, Transformer Load Housing, Voltage Transformer Load Box, Current Transformer Load BoxPTLoad boxCTLoad Box, Voltage Transformer Load Box, Current Transformer Load Box

Environmental Conditions Temperature:15～25℃ Humidity:<80%(25℃)

Elevation:<1500mPower Frequency:50Hz

Rated Capacity:COS0.8:2.5VA～60VA COS1.0:2.5VA～20VA

Measurement Range Electric Current 1%～120%

Secondary Current 5A

Power Factor 0.8、1.0

Accuracy ±3%±0.0025VA

Test Voltage 2kV

Physical Dimensions(Length x Width x Height) 250×350×175mm3

Weight 8kg
